1-screen X-ray film viewer M-NI series
white light

1-screen X-ray film viewer
1-screen X-ray film viewer
Add to favorites
Compare this product


Characteristics

Number of screens
1-screen
Other characteristics
white light

Description

Stove enamelled steel structure thickness 0,8 mm. Fire epoxy painting colour peel RAL 9010, upon structure cleaning treatment Smelted opaline acrylic screen thickness 3 mm inserted into the structure Neon tubes of 6.000°Kelvin (other type of tubes available on request) Speed bipolar switches on the front Upper and/or central pressing rolls film holding system External fuses lagging type 5×20 (positioned on the bottom right side) Feeding cable complete with plug and earth “Italian” type 180 long Integrable with other optional devices like: lateral support for spot viewers and/or magnifying lens, trolley on wheels. X-ray film viewer conforms to Directive 93/42/CEE – Medical Devices – Class 1 Moreover meets the Directive 73/23 CEE (Low tension) 89/336 CEE (Electromagnetic compatibility). The construction conforms to Norms EN 60601 -1,2 – Din 6856 -1,2 Feeding 230V / 50Hz + earth Maintenance: recurrent cleaning (each 6 months) of the whole screen and tubes replacement each 5.000 hours of use.
