Sterilizer steam generator Unotherm II

for autoclaves

If a supply of pure steam is not available on site, your sterilizer can be operated together with an MMM steam generator. No matter how your facilities are laid out, the steam generator can be integrated into the sterilizer, or can be installed next to, above or away from the steam consumer. The steam generator can be conveniently operated from the sterilizer control panel. The technical highlights: The boiler performance can be optimally adjusted to the requirements of the connected consumer in 9 kW steps from 36 to 81 kW Thermal degassing to reduce the proportion of non-condensible gases in the steam Low electrical connected power required Rated power: between 36 and 54 kW or 63-81 kW Pressure limiter: 3.2 bar For an independent pure steam supply The Unotherm II is a pure steam generator that offers high performance with low energy requirements. It has been specially designed for facilities without a central steam supply. It can also be used for cost-effective steam generation in an emergency or on weekends. The boiler output can be optimized to meet the specific requirements of the connected sterilizer. For example to keep the proportion of non-condensable gases in the sterilization steam as low as possible, the boiler feed water is thermally degassed in a process controlled and monitored by a temperature sensor. The quality of the boiler water is maintained at a constant high level by automatic blow-down. The blow-down can optionally be conductance-controlled. This completely eliminates the possibility of performance being affected due to deposits and corrosion.
