Superior Image Quality
High MTF & DQE
Pixel Pitch : 145 ㎛
Real-time Image Correction
Designed for RF Systems
Frame Rate : 14 fps @ 1 x 1 / 46 fps @ 2 x 2
Specification
Technology a-Si TFT
Scintillator CsI
Spatial Resolution 3.4 lp/㎜
Pixel Matrix 2048 x 2048 pixels
Grayscale 16 bits
Max. Frame Rate Full size: 14 fps 2x2 binning: 30 / 46 fps
Data Interface Gigabit Ethernet
Dimensions 32.8 ㎝ x 32.3 ㎝ x 5.0 ㎝
Weight 4.1 kg
Boot-up Time less than 30 s
Operating Environment 10℃ to 35℃ 30 % to 85 % RH (non-condensing)
Power Consumption DC 12 V, 2.5 A
