CHARACTERISTICS
- Fully automated optical structured-light scanner with three high-resolution high-speed cameras with particularly high scan data density and less rescanning
- Even faster scanning thanks to further developed software technology (starting from Zirkonzahn.Scan 5051)
- High scanning precision: ≤ 10 μm
- Particularly large scanning area (115 x 78; format 16:9) for articulator scans and the capture of the entire model in a single scanning process; every kind of lab articulator can be measured and stored in the software
- The placement of the third camera allows a deeper detection area for interdental spaces and for impressions
- Scannable objects: no limitations, i.a. individual dies, arch segments, full arch models, bite records, opposing dentition (mush bites, entire jaw), wax-ups, veneers, abutments, occlusal registrations, bite rims, etc.
- Double-Scan function
- Integrated colour scan option – useful for example when creating partial dentures
- Extensive matching functions, for example group matching, marker matching, negative matching
- Stable high-precision gears
- Scanning area is protected from unfavourable lighting conditions and dust
- Universal capturing of models with intelligent model acquisition concepts and fast clamping devices (Easy-Fix-System)
- Easy positioning of the scan model with the help of a laser point
- Patient-specific information captured with the PlaneSystem® (Udo Plaster, MDT) and with the Plane Analyser, can be 100 % digitised and implemented into the Zirkonzahn.Software
- Software and hardware upgradeable to the latest technology
