仕様
バス互換性 - PCIe Gen3 x8
消費電力 - < 35W
フォーム・ファクタ - 168 mm (L) x 60mm (H) single wide PCIe slot
オペレーティング・システム - Windows 7 (64-bit), Windows 10 (64-bit)
プラットフォーム - Intel® and AMD architectures
電源コネクター -
グラフィック・アクセレレーター - AMD Radeon Pro™
ディスプレイ・メモリ - 2GB DDR5
メモリ・インターフェース - 64-bit
メモリ帯域幅 - 48 GB/s
ピクセル深度 - 32-bit pixels (10-bit grayscale and 30-bit color)
電気規格 - DisplayPort (DP) v1.4
Direct3D ハードウェア・サポート - Microsoft® DirectX v12, Vulkan® 1.1, Shader Model 5.1
OpenGL ハードウェア・サポート - OpenGL 4.5
端子 - (1x) DisplayPort 1.4 (2x) Mini-DisplayPort 1.4
接続性 - Native DisplayPort suggested
DisplayPort to Single-link DVI adapter available separately
(2x) Mini-DP to DP locking adapters included
認定およびコンプライアンス - FCC Part 15 Class B, CE EN 55032 Limit B, EN 55024, UL-60950-1, BMSI CNS, CISPR- 32/24, IEC609050-1, VCCI, CSA C22.2, EU RoHS directive (2011/65/EU), Certificate of Information & Communication Equipment (Republic of Korea)
動作温度 - 0° to 55°C
