Gas micropumps

Pressure: 500 mbar

... controlable flowrate 8 µl/min up to 8.000 µl/min typ. flow rate 6 ml/min & typ. back pressure 500 mbar @100 Hz, 250 Vpp, SRS signal gas: min. flow rate 12 ml/min & min. back pressure 80 mbar @100 Hz, 250 Vpp, SRS signal material ...

Pressure: 100 mbar

technical data - typ. flow rate 20 ml/min typ. back pressure 100 mbar @300 Hz, 250 Vpp, SRS signal material in contact with media: PPSU lifetime:5.000h Pump type piezoelectric diaphragm pump Number of actuators 2 Dimensions ...

Pressure: 150 mbar

technical data - typ. flow rate 20 ml/min typ. back pressure 150 mbar @300 Hz, 250 Vpp, SRS signal material in contact with media: PPSU lifetime: 5.000h Pump type piezoelectric diaphragm pump Number of actuators 2 Dimensions ...

Pressure: 450, 500, 600 mbar

Pneumatic performance free flow at outlet:400 ml/min450 ml/min550 ml/min at 100 mbar:340 ml/min340 ml/min400 ml/min max. pressure:500 mbar450 mbar600 mbar at -100 mbar:270 ml/min300 ml/min400 ml/min max. vacuum:-400 mbar-400 mbar-500 mbar

Pressure: 550, 620, 650 mbar

Operating voltage6 Vdc9 Vdc12 Vdc Pneumatic performance free flow at outlet:550 ml/min600 ml/min620 ml/min at 100 mbar:400 ml/min450 ml/min450 ml/min max. pressure:550 mbar650 mbar620 mbar at -100 mbar:350 ml/min450 ml/min400 ml/min max. ...

Pressure: 500 mbar

Operating voltage3 Vdc Pneumatic performance free flow at outlet:500 ml/min at 100 mbar:350 ml/min max. pressure:500 mbar at -100 mbar:300 ml/min max. vacuum:-420 mbar

Pressure: 550 mbar

Operating voltage3 Vdc5 Vdc Pneumatic performance free flow at outlet:600 ml/min600 ml/min at 100 mbar:400 ml/min400 ml/min max. pressure:550 mbar550 mbar at -100 mbar:350 ml/min350 ml/min max. vacuum:-550 mbar-550 mbar

Pressure: 600, 700, 1,500 mbar

Operating voltage4 Vdc6 Vdc12 Vdc Pneumatic performance serial/parallelserial/parallelserial/parallel free flow at outlet:430 / 850 ml/min550 / 1000 ml/min430 / 850 ml/min at 100 mbar:390 / 700 ml/min500/ 850 ml/min390 / 700 ml/min max. ...

Pressure: 650 mbar

... -LC proves to be an optimal solution for a price-sensitve mass production. Made for portable machines, especially for gas analysis. Gas-tight pump heads allow the unaltered delivery of the media. Specific ...

Pressure: 400 mbar

... with special long life ball bearings, as in the SP 250 EC-DB (“double ball”). Made for portable machines, especially for gas analysis. Gas-tight pump heads allow the unaltered delivery of the media. Specific ...

Pressure: 600, 700 mbar

Operating voltage3 Vdc5 Vdc12 Vdc Pneumatic performance free flow at outlet:580 ml/min600 ml/min600 ml/min at 100 mbar:450 ml/min400 ml/min500 ml/min max. pressure:600 mbar600 mbar700 mbar at -100 mbar:400 ml/min400 ml/min500 ml/min max. ...

Pressure: 600 mbar

Operating voltage5 Vdc9 Vdc12 Vdc Pneumatic performance free flow at outlet:600 ml/min600 ml/min600 ml/min at 100 mbar:500 ml/min500 ml/min400 ml/min max. pressure:600 mbar600 mbar600 mbar at -100 mbar:500 ml/min500 ml/min400 ml/min max. ...

Pressure: 700 mbar

Operating voltage12 Vdc Pneumatic performance free flow at outlet:700 ml/min at 100 mbar:550 ml/min max. pressure:700 mbar at -100 mbar:500 ml/min max. vacuum:-600 mbar

Flow: 0 l/min - 6 l/min
Pressure: 0 psi - 6.19 psi

Low-frequency therapeutic devices Medical examination equipment Gas detectors Gas analysis equipment

Flow: 0 l/min - 1.5 l/min
Pressure: 0 psi - 3.87 psi

Sphygmomanometers Medical examination equipment Dental treatment devices Inkjet printers
