– Directive 2006/42/CE | Machine Directive
– Directive 2004/108/EC | EMC Electromagnetic Compatibility
– UNI EN ISO 10535 | Hoist For The Transfer of Disabled Persons
– 93/42/CEE | Medical Device Directive
Lenght - 1267 mm - 1294 mm
Width - 640 mm - 640 mm
Height - 1512 mm - 1607 mm
Seat max height - 512 mm - 484 mm
Seat travel down - 595 mm - 745 mm
Structure Materials -
Aluminum / Stainless Steel
Nr of Wheels -
4 (2 with brake)
Lifting structure -
Parallelogram
Painting -
Powder Coating
Safety -
Anti-Tip and Stabilizing System – Patented
Lifting Capacity -
136 Kg (120 Kg i-swim L)
Own Weight -
ca. 140 Kg
Voltage -
24V
Battery datas -
2 Batteries – 2 x 18Amp
Battery Working range -
50 Cycles approx
Battery Charger - Included
Instruments (on Handrail) -
Battery Load Indicator
Up-Down
Push Buttons
Emergency
Stop Button
