Electronic ventilator NOCCARC V310
intensive careinfantnon-invasive

electronic ventilator
electronic ventilator
electronic ventilator
electronic ventilator
electronic ventilator
electronic ventilator
electronic ventilator
Add to favorites
Compare this product


Characteristics

Type
electronic
Applications
intensive care
Patient type
infant
Ventilation mode
non-invasive
Configuration
on casters, portable

Description

Noccarc V310 offers an advanced, compact yet reliable ICU ventilation solution. Carefully crafted with the combination of cutting edge research and advanced manufacturing technologies, the turbine based design enables highly efficient independent operation and a wide range of ventilation modes, including High Flow Nasal Cannula. The IOT enabled system allows central data monitoring and logging remotely making Noccarc V310 a much safer and easy to manage option for the health professionals in the current case of Covid-19 pandemic. Modes of Ventilation Invasive and Non Invasive: PC-CMV, PC-AC, PC-SIMV, VC-CMV, VC-AC, VC-SIMV, PRVC-CMV, PRVC-AC, PRVC-SIMV, PS/CPAP (PSV), APRV High Flow Nasal Cannula (HFNC mode) Quick Ventilation Mode for Emergency Use Apnea Backup Ventilation echnical Specification Peak Pressure - 60 cm H2O Peak Respiratory Rate - Up to 80 BPM Inspiratory Time - 0.2 - 5s Tidal Volume - 50 - 2000 ml Peak Flow Rate - 280 SLPM (Internally restricted to 160 SLPM) PEEP - 0 to 40 cm H2O (Increment of 1 cm H2O) Pressure Support - 0 to 50 cm H2O Inspiratory Hold - Yes Expiratory Hold - Yes I:E Ratio - 1:6 to 6:1 Trigger Flow Sensitivity - 1 SLPM - 20 SLPM Volume Accuracy - 2-3 % of the full scale between 10 LPM - 80 LPM Leak Detection and Compensation - Yes Quick Ventilation Mode for Emergency Use - Yes Programmable SIGH - Yes Electronic FiO2 Manipulation - Yes FiO2 Manipulation between 21% to 100% - Yes FiO2 Delivery Independent of Flow rate, PEEP and Minute Volume - Yes Dimensions - 395 X 340 X 255 mm Weight - 10.1 Kg Oxygen Input Pressure - 45 - 60 PSIG Battery Type - Lithium Ion

Catalogs

No catalogs are available for this product.

See all of AVI Healthcare‘s catalogs
