Laboratory washer-disinfector MITO FBS

reprocessingbottlefloor-standing

Product overview
MITO FBS is a semiautomatic feeding bottle washer with an integrated filling system designed for small-size animal research laboratories. It performs automatic emptying, washing, rinsing and filling of 18 bottles per cycle, ensuring complete reprocessing of bottles and caps with minimal footprint and low operating cost.

Frictionless organic workflow
The system core is a rotating mechanism that executes bottle emptying, washing, rinsing and filling in a seamless four-step workflow:

• filling system
• top rinsing system
• washing system
• bottom rinsing system

The crate rotates 180° to discharge residual water. Bottles undergo internal and external rinsing at 85°C for sanitization. After a dripping phase the crate returns upright for final filling. All operations are automatic to reduce manual handling and process time.

In-line system solution
MITO FBS is modular and supports in-line configurations to match operational layouts: examples include a loading table with ultrasonic bath, rinsing tap and manual cap remover, followed by the washing/filling unit and an unloading/drip station. The emptying/dripping stations are available with AISI 316L stainless steel worktops and central drainage.

Option — Drinking water acidification unit
Optional acidification unit treats drinking water supplied to the filling modules to reduce bacterial load. The unit can be positioned adjacent to the FBS workstation or integrated into a side cabinet on request.

Features

• Design and hygiene – Chamber, boiler tank and washing/rinsing circuits in stainless steel AISI 316L (DIN 1.4404) for long-term reliability and easy cleaning.
• Effective sanitization – Individual nozzles provide full internal and external bottle coverage; disinfecting rinse at 85°C.
• High cleaning performance – Independent washing and rinsing circuits ensure optimal cleaning.
• Automatic detergent dosing – Peristaltic pump for precise liquid detergent dosing.
• Process monitoring – Separate PT1000 temperature probes for sump and boiler, plus a chamber water level sensor to prevent overflow.
• Control system – Microprocessor control with LCD panel, RS232 port and up to 40 program slots.

Certifications
Meets European standards EN 61010-1, EN 61010-2-040 and EN 61326-1.

Dimensions
MITO FBS Module
External dimensions – Hood closed (WxDxH)
650 x 700 x 1465 mm
26 x 28 x 58 in
External dimensions – Hood open (WxDxH)
650 x 700 x 1865 mm
26 x 28 x 73 in

Technical specifications

• Capacity: 18 bottles per cycle
• Operations: automatic emptying, washing, rinsing, dripping and filling
• Material: chamber, boiler tank and circuits in stainless steel AISI 316L (DIN 1.4404)
• Sanitization: internal and external rinse at 85°C (185°F)
• Washing/rinsing: independent systems; individual nozzles for full bottle coverage
• Detergent dosing: automatic via peristaltic pump
• Temperature control: separate PT1000 probes for sump and boiler
• Water level: chamber water level sensor to prevent overflow
• Control: microprocessor system, LCD display, RS232 port, up to 40 programs
• Modularity: configurable with multifunctional loading/unloading tables and accessories (ultrasonic baths, rinsing taps, manual cap remover, dripping/unloading stations)
• Optional: drinking water acidification unit for treated water feeding into filling modules
• External dimensions (hood closed): 650 x 700 x 1465 mm
• External dimensions (hood open): 650 x 700 x 1865 mm
• Standards: EN 61010-1, EN 61010-2-040, EN 61326-1
