Zero experiment maze LE841

elevated plusfor animal researchfor behavioral research

Presentation
Modification of the classic Elevated Plus Maze, the BIOSEB Zero-Maze is a laboratory apparatus for the evaluation of anxiety-like behaviour in rodents. It provides an alternative layout to the elevated plus maze by removing the central platform, reducing ambiguous positional classification during behavioural scoring.

Operating principle
With no central area, the subject is always located in either a closed arm or an open arm. This design simplifies interpretation of time spent and entries per area and reduces ambiguous allocation of behaviours when quantifying anxiety-related endpoints.

Intended species

• Rats
• Mice

Models

• LE845 – Zero Maze for Mice
• LE841 – Zero Maze for Rats

Technical specifications

• Reference: LE841 (reference shown on product page)
• Dimensions – LE841 (Rat): External diameter 1050 mm; Internal diameter 850 mm; Wall height 295 mm; Base elevation 510 mm
• Dimensions – LE845 (Mouse): External diameter 460 mm; Internal diameter 350 mm; Wall height 70 mm; Base elevation 500 mm
• Materials: Methacrylate (PMMA)
