32-channel EEG cap

16-channelpediatricS

Wireless, gel-free EEG cap with 16 or 32 channels, designed for pediatric research in real-world environments. Comfortable for children, practical for researchers. Technical specifications Hardware Versatile 32ch EEG Sensors and Headset - EEG Channels - 32x EEG + REF + GND - Type of sensors - Water-based sensors, active shielding and optimized DRL - Head perimeter - 420-660 mm (Cap sizes S, S/M, M, M/L, L, XL) Wireless Amplifier - Sampling rate / Resolution - 256 SPS at 24 bits - Bandwidth - DC-70 Hz (3rd-order LPF) - Real-time check impedance - Yes (relative contact impedance) - Integrated sensors - Integrated IMU (9 axis): Accelerometer, gyroscope and magnetometer - Other inputs - 1x Optical Trigger, 1x Digital Input, 2x Bipolar ExG - Input range and noise - ±100 mV, 50 GΩ - Dimensions - 107 x 74 x 32 mm - Weight - 165 g What is included Amplifier EEG cap + chinstrap Kids Cap Set of EEG electrodes + connectors Sensor holder Sensor sockets Wet sensors (sponges) Measuring band 8GB Class-10 MicroSD card with SD adaptor Charger + adapters EEG Cap EEG cap available in multiple pediatric sizes for infants and children, ensuring fit and signal quality, with flexible sensor placement following the 10-20 and 10-10 systems. Kids Cap Child-friendly cover that protects sensors and makes the system more approachable and friendly for kids. Kids Cap EEG Amplifier Lightweight amplifier with integrated motion tracking, Bluetooth transmission, and microSD card backup storage for reliable data recording. Software Versatile Kids EEG uses SennsLite for raw data acquisition,
