Medical trolley CTPHLEM1/10/4S1D
for intravenous proceduresplasticmetal

Medical trolley - CTPHLEM1/10/4S1D - Bristol Maid Hospital Metalcraft - for intravenous procedures / plastic / metal
Medical trolley - CTPHLEM1/10/4S1D - Bristol Maid Hospital Metalcraft - for intravenous procedures / plastic / metal
Medical trolley - CTPHLEM1/10/4S1D - Bristol Maid Hospital Metalcraft - for intravenous procedures / plastic / metal - image - 2
Add to favorites
Compare this product
Go to the Bristol Maid Hospital Metalcraft website for more information

Characteristics

Applications
medical
Function
for intravenous procedures
Material
plastic, metal, stainless steel
Components
with waste bin, with tray, with hand sanitizer dispenser holder, with laptop support
Configuration
mobile
Ergonomics
side-access, top-access
Other characteristics
secure, with electronic lock

Description

FEATURES

  • Trolleys designed for use with phlebotomy procedures
  • Quick and easy disassembly to enable thorough deep cleaning
  • Available in mild steel or 304 grade stainless steel
  • Frame options: fully welded mild steel frame or seamlessly welded one-piece 304 stainless steel frame
  • Ergonomic push handle fitted to one side to promote correct posture and keep feet clear of the frame (suitable for mobile phlebotomy)
  • Recyclable polypropylene one-piece top and side panels with smooth surfaces and radiused edges to assist cleaning (compatible with steam cleaning)
  • Top panel: raised edges on three sides provide defined grab points to act as push handles; integral front rim contains spillages (maximum load 30 kg)
  • Side panels: runners with positive stops prevent trays from being accidentally withdrawn; symmetrical design allows tray insertion from either side
  • Carerails fitted to either side to support a wide range of accessories
  • Optional secure door and back panel available to provide security for tray contents
  • Two locking options: CAM lock with wing handle (supplied with two keys) or electronic push button lock (programmable four-digit code)
  • Trolley pre-configured with accessories: alcohol gel holder; debris bin & bracket; glove/mask box holder (one box); sharps box holder
  • Trays: translucent, impact-resistant with smooth surfaces and radiused edges to assist cleaning (compatible with steam cleaning and high-temperature machine washing)
  • Trays include integral handle with plastic clip-on label cover; coloured labels supplied (white, blue, green, yellow and red)
  • Each tray supplied with 2 long and 2 short dividers
  • Polyurethane ring buffers to protect both the trolley and building fabric
  • 100 mm polymer castors, two with brakes


DIMENSIONS (w x d x h)

  • Overall dimensions: 610 x 550 x 993 mm
  • Plastic top internal: 455 x 455 mm at height 968 mm
  • Trays (internal):
    • Shallow tray: 355 x 405 x 100 mm (internal)
    • Deep tray: 355 x 405 x 150 mm (internal)


STANDARD COLOURS

  • Paint: Spearmint


INCLUDED / COMPATIBLE ACCESSORIES (examples)

  • Phlebotomy armrest
  • Security seals and clamps
  • Work flap
  • Overbridge
  • Tilt bins
  • Adjustable defibrillator platform
  • Alcohol gel holder
  • Airway tube holder
  • Debris bin & bracket; waste bin & bracket
  • Sharps box holder / universal sharps box bracket
  • Document holder
  • Additional trays, dividers and coloured label strips
  • Laptop holders (removable and non-removable swing arm)
  • Polymer castors


Notes

  • Top panel maximum load: 30 kg
  • Maximum load per tray: 5 kg


Technical specifications

  • Product family: Caretray Trolley (Phlebotomy)
  • Materials: mild steel (welded) or 304 grade stainless steel (one-piece welded)
  • Top and side panels: recyclable polypropylene
  • Tray material: translucent impact-resistant polymer (steam/high-temperature washable)
  • Castors: 100 mm polymer castors, 2 with brakes
  • Buffers: polyurethane ring buffers
  • Locking options: CAM lock with wing handle (2 keys) or electronic push button lock (programmable 4-digit code)
  • Tray handle labels: plastic clip-on covers; supplied colours white, blue, green, yellow, red
  • Overall dimensions (W x D x H): 610 x 550 x 993 mm
  • Shallow tray internal: 355 x 405 x 100 mm
  • Deep tray internal: 355 x 405 x 150 mm
  • Top internal: 455 x 455 mm at 968 mm height
  • Top panel spill containment rim and raised grab edges
  • Designed for easy disassembly and compatibility with steam cleaning
