Wall-mounted fan coil unit COMFORT LINE™ X

The CIAT Comfort Line™ X is available in different sizes with 2-pipe, 2-pipe plus electric heater or 4-pipe coils, with an air flow range from 140 to 1900 m³/h, a total cooling capacity range from 0.6 kW to 11kW and a nominal heating capacity range from 0,8 kW to 14 kW. Modular Horizontal ducted unit Extremely quiet operation Low Energy Consumption Flexibility for simplified installation Improved comfort Efficient Indoor Air Quality Cooling capacity : 0,6-11 kW Heating capacity : 0,8-14 kW Air flow : 140-1,900 m³/h Description General description Compact and modular ducted unit, designed for any false ceiling installation Reliable and economical for tertiary building Low height Extremely low sound levels for ducted applications Low Energy Consumption variable-speed EC motor High-pressure centrifugal fan Factory installed options for fast and easy installation in false ceilings Configuration flexibility With free inlet and/or outlet With a rectangular flange air inlet and/or outlet (practical to connect the fan-coil unit to the air ductwork) With inlet and/or outlet plenums including large number of spigots diameters 160, 200 or 250 mm according to unit size Features Stand alone thermostats V6+ 2 types of thermostats: Type C : two-pipe applications equipped with electric heating and EC motor Type D : a four-pipe application equipped with EC motors Wall-mounted controls can easily and discreetly be integrated into any room environment. The operating range goes from 10°C to 30°C. Communicating thermostat V600 One thermostat for all fan coil application Lead/lag function to synchronize equipment in open space KNX bus for communication
