Cardiac stress test equipment CONTEC8000S

with treadmillwith exercise bike

Introduction
The Stress ECG Analysis System consists of a sampling hardware device, dedicated analysis software and compatible exercise equipment. It provides synchronous 12‑lead ECG acquisition and continuous data storage, real‑time ST segment monitoring, multiple review modes during and after exercise, multi‑parameter trend analysis and a range of printable diagnostic reports. The system records exercise state and ECG continuously to support clinical diagnosis and reporting.

Main Features

• Real‑time ECG waveform printing during acquisition and full recording of the exercise session.
• Real‑time observation of ST segment changes, selectable lead enlargement and automatic ST‑related calculations.
• Anti‑interference technology to stabilise baseline and reduce EMG, baseline drift and AC artifacts.
• Support for standard and custom exercise protocols; configurable automatic actions per exercise phase (e.g. instant print notifications, BP measurements).
• Operator event marking during exercise; marked events can be compared to current waveforms and reviewed, edited and printed after the test.
• Display and print various trend charts (HR, BP, METS, HR×BP, exercise trend, ST metrics including level/influence/slope/3D/J level, ST/HR).
• Dynamic, static and superimposed review functions to represent the entire exercise testing process.
• Case import/export and compression to save storage space and simplify data transfer.
• System settings include language switch (Chinese/English), multiple waveform display layouts, background colour, print and filter settings and optional parameter display.
• Tools for device management, case statistics and system maintenance.
• Wireless ECG data sampling mode to improve anti‑interference performance.
• Compatible with a variety of exercise devices (treadmill, cycle ergometer, etc.).

Technical specifications

• Model designation: CONTEC8000S (Stress ECG Analysis System).
• Acquisition: synchronous 12‑lead ECG sampling.
• Data handling: continuous recording and storage of entire exercise ECG session; case compression for storage and easy import/export.
• ST analysis: real‑time ST segment monitoring with automatic ST‑related calculations and selectable lead enlargement.
• Review modes: dynamic review, static review, superimposed review of ECG during exercise and post‑exercise analysis.
• Trend analysis: multi‑parameter trend charts (HR, BP, METS, HR×BP, exercise trend, ST metrics including level/influence/slope/3D/J level, ST/HR).
• Printing: real‑time waveform printing during sampling; multiple printable report formats.
• Interference mitigation: anti‑interference technology for baseline stabilization and reduction of EMG/AC/baseline drift artifacts.
• Exercise protocols: supports standard and user‑defined exercise protocols; configurable automatic actions per exercise phase (e.g. print, BP measurement).
• User interface: multiple waveform layout modes and colour/background customization; language switch (Chinese/English).
• Connectivity: wireless ECG data sampling mode supported.
• Compatibility: supports various exercise equipment types (treadmill, cycle ergometer, etc.).
• System utilities: tools for device management, case statistics and system settings.
