Medical controller MC20

digital

The MC20 single-fault-proof distributor contains all the requirements and features needed to best configure a functional nursing or hospital bed. This distribution unit can either be mounted directly on the Megamat20 single drive or attached separately to the bed system. Up to 8 further BUS-compatible components can be connected. An additional hub can be used for an extension. The plug-in slots can be assigned flexibly as needed. There are a wide range of compatible accessories that can be used to help configure the bed to fit requirements. The housing of the MC20 has a high protection class of IP66 so that no foreign liquids or dust can penetrate and it is easy to clean. This distributor features an optimal price-performance ratio. It is also compatible with all other intelligent components of Dewert, which together form a digital BUS system. Free assignment of slots Extension with further hub possible Many compatible accessories (SMPS, operating devices, sensors, lights, Bluetooth) Technical data Duty cycle 2/18 min. or 10 %, max, 5 switching cycles per minute Control unit DCC 2.0 Powerbus Output voltage 29 V DC constant Housing colour light grey RAL 7035 Safety Single-fault protection SMPS yes Connectivity Up to 8 bus members (4 with integrated SMPS) Protection type IP66 Protection class II/III Relative humidity 30% – 75% Ambient temperature +10°C - +40°C Power supply 29 V DC (without SMPS), wide input voltage range 100-240 V AC (with SMPS) Safety single-fault protected Assembly options fastening drill-holes/direct fixing to Megamat 20
