Hand-held bladder scanner EdgeFlow UH10

Overview
EdgeFlow UH10 is a dedicated bladder ultrasound scanner designed for fast single‑scan bladder volume measurement. It combines deep‑learning contour detection with dual‑plane imaging to support efficient, noninvasive assessment in clinical workflows.

Key Technologies
EdgeFlow UH10 integrates advanced image processing: LiveContour™ for automatic bladder contour identification, MaxContour™ for image optimization from image series, and the DualActive™ probe for simultaneous sagittal and transverse views to capture the largest bladder cross‑section in a single acquisition.

Features

• MaxContour™ — Optimizes a representative image from a sequence to improve measurement consistency.
• LiveContour™ — Automatic bladder contour detection for rapid and repeatable volume computation.
• Ergonomic design — Lightweight, easy‑grip housing and intuitive user interface adapted for clinical use.
• Cradle station — Combined charging and printing cradle to streamline bedside workflow.
• DualActive™ probe — T‑shaped array enabling simultaneous sagittal and transverse imaging with one scan (dual‑plane acquisition).

Media
Instructional and promotional videos demonstrate DualActive™ probe handling, recommended clinical use, and step‑by‑step operational guidance for clinical staff.

Product Documents (available on site)

• [Clinical Insights] EdgeFlow UH10_Bladder Scanner in Critical…
• [White Paper] EdgeFlow UH10 vs. Catheterization Accuracy Com…
• [Product Brochure] EdgeFlow UH10 Bladder Scanner

Technical specifications

• Product name: EdgeFlow UH10
• Application: Bladder ultrasound volume measurement
• Measurement method: Single‑scan volume measurement using deep‑learning contour detection
• Imaging: Dual‑plane (sagittal and transverse) imaging with DualActive™ probe
• Image processing: MaxContour™ (image optimization from series) and LiveContour™ (automatic bladder contour identification)
• Probe type: T‑shaped DualActive™ probe for simultaneous dual‑plane viewing
• Design: Ergonomic, lightweight housing with intuitive user interface
• Accessories: Cradle station with printing and charging functions
