Dog veterinary MRI system Supreme Zero

for felinesfor small animalsfor large animals

Product overview
Developed with veterinarians, reference centers and clinical partners, Supreme Zero is a veterinary-dedicated 1.5T MRI system that combines clinical-grade imaging with a user-centred interface. The system is engineered to simplify daily workflows for veterinary teams while providing diagnostic-quality imaging across species and sizes.

Advanced veterinary MRI performance
Supreme Zero is the first Esaote helium-free 1.5T MRI designed specifically for veterinary medicine. It delivers 1.5T image quality and speed for accurate visualization of anatomical regions. The fully helium-free architecture removes the need for a quench pipe, simplifies installation, lowers maintenance constraints and supports long-term operational sustainability.

Key benefits

• 60 cm bore — optimised for imaging small and medium-sized animals
• Zero helium — fully helium-free superconductive design
• Multi-channel coils — dedicated veterinary coil portfolio for high-quality scans
• Veterinary-focused — hardware and software tailored to veterinary workflows
• Single-operator workflow — protocols and interface enabling efficient one-person exams

Workflow and clinical protocols
Supreme Zero supports true single-operator workflows and includes an extensive library of anatomical protocols developed with veterinary experts. Protocols are preconfigured by species and size to ensure repeatable, high-quality images with reduced setup time.

Clinical images
Clinical examples demonstrate high-resolution anatomical imaging across small animals (canine, feline breeds such as chihuahua, labrador, shar‑pei, maine coon) and larger species (e.g., czechoslovakian wolfdog). Sequences include transverse, sagittal and dorsal views using T1w, T2w, FLAIR, SWI and contrast-enhanced protocols.

Vet MRI coils (examples)

• Small head coil (4‑channel)
• Flexible coil (8‑channel)
• Large head coil
• Neck‑thorax coil
• 12‑channel body coil
• 16‑channel head coil
• 24‑channel flat spine coil

Customer service & maintenance features
Remote service capability enables system parameter checks and diagnostics. The system is upgradeable to follow technological advances and is offered with service coverage options to support clinical uptime and planned maintenance.

Technical specifications

• Field strength: 1.5T MRI
• Bore diameter: 60 cm
• Helium: fully helium-free design (zero helium)
• Coils: multi-channel veterinary coil solutions (small head 4ch, flexible 8ch, large head, neck-thorax, 12ch body, 16ch head, 24ch flat spine)
• Workflow: single-operator workflow support with veterinary-specific protocols
• Design focus: dedicated veterinary interface and hardware
• Clinical capability: supports T1w, T2w, FLAIR, SWI and contrast-enhanced imaging across multiple animal sizes and species
• Service: remote technical support and upgradeability; service contracts available
