Abdominal crunch gym station PC2029

back extension

Product description
The Etenon Fitness PC2029 combines a compact, ergonomic layout with professional-grade components to perform targeted work on the abdominal and lumbar (lower back) regions. The dual-function design allows isolated abdominal crunches and lumbar extensions. An adjustable padded roller arm and ergonomic supports enable individualized setup and natural, fluid movement for effective strengthening and rehabilitation-oriented training.

Key features

• Dual-function operation for abdominal and lumbar exercises.
• User-adjustable padded roller arm for targeted positioning.
• Cam system and counter-balanced arms for uniform resistance throughout the stroke.
• Safety fairings and clear weight indicators (kg/lbs) for secure use in commercial environments.

Technical characteristics

• Structure: 3 mm thick oval steel tube.
• Movable parts mounted on 0.5 cm thick plates; removable parts made of solid steel.
• Bearings (circular or linear) or bronze wheels used in moving assemblies.
• Counter-balanced arms reduce perceived load; cam system ensures consistent resistance curve.
• Four-layer paint treatment for corrosion protection (degreasing, phosphating, pre-phosphate, epoxy powder finish).
• Calibrated steel plates painted black with high-quality Teflon rings for smooth sliding and reduced friction noise.
• Magnetised plate selectors and plate tower with kg/lbs indicators.
• Stainless steel guide bars; transmission via 3 mm reinforced cable with 2 mm protective sheath.
• Front and rear polycarbonate fairings to prevent access to moving plates.
• Adjustable padded lumbar/abdominal support; red adjustment selectors for quick identification.
• Non-absorbent, non-slip rubber grips; two large trays for bottle and personal items.
• Upholstery: viscoelastic padding with antibacterial and fireproof imitation leather.
• Structure warranty: 7 years.

Dimensions and weight

• Length: 131.4 cm.
• Width: 112 cm.
• Height: 150 cm.
• Machine weight: 227 kg.
• Total plate load: 108.86 kg.

Model / specifications

• Model: PC2029; Series: PC20 (abdominal-lumbar).
• Weight stack capacity: 108.86 kg.
• Transmission: 3 mm reinforced cable with 2 mm sheath; bearings or bronze wheels on moving parts.
• Intended use: commercial and professional fitness facilities, rehabilitation centers.
• Warranty: 7 years on structure.
