Dental contra-angle GL-15L

electricspeed-decreasingangled

Product details

• Product Code: 70-1120-GLH0002
• Product Type: Electric handpiece (contra-angle)
• Manufacturer: Prismatik Dentalcraft, Inc.

Description
The Glidewell GL-15L contra-angle electric handpiece features high-precision German Myonic bearings with a swing amplitude below 0.01 mm for stable, accurate rotation. Manufactured using multi-axis Swiss and Japanese machines, it is designed for precision procedures in limited access areas. The 91.5° angled head facilitates anterior restorations and polishing. Integrated LED fiber-optic illumination provides uniform, high-intensity lighting to improve visibility during cutting, grinding and drilling. The handpiece accepts standard burs and rotary instruments and is driven by electric motors with an E-type connector (ISO 3964).

Features

• Low operational noise
• Adjustable, accurate speed with stable cutting force
• Long service life
• Compatible with electric motors using standard E-type (ISO 3964) coupling

Technical specifications

• Model: GL-15L
• No-load speed: ≤ 212500 r/min
• Chuck type: Mechanical chuck
• Speed ratio: 1:5
• Handpiece coupling: Standard E-type interface (ISO 3964)
• Surgical instruments: Type 3, Ø 1.6 mm bur (ISO 1797-1)
• Bur length: 20–25 mm
• Max bur tip diameter: 2 mm
• Shank size: ISO 1797-1 Ø 1.6 mm
• Minimum shank length: 12.5 mm
• Cooling pressure range: 1.5–3 bar (recommended 2 bar)
• Cooling air consumption at 2 bar: > 1.5 Nl/min
• Lighting mode: Optical fiber (output illumination > 7000 lx)
• Lighting source: LED SG15L (20000–65000 lx)
• Water cooling: ≥ 50 mL/min at 200 kPa (2.0 bar)

Warranty
One-year warranty covering defects in materials and workmanship under normal use. Warranty excludes damage from misuse, accidents or improper handling (including drops or physical impacts).
