Oxygen cylinder support 113-012

rail-mountedaluminumheight-adjustable

Product name
Carrying board 113-012

Art-No.
113-012

Product types

• Medical device
• Intermediate product

Product details
Base (WxD): 400 x 250 mm
Height: 390 mm
Rear edge (WxD): 41 x 50 mm
Rail profile (DIN EN ISO 19054): 25 x 10 x 390 mm
Raster for standard rail: 50 mm
Weight: approx. 2.4 kg
Max. payload: 2 kg
Material: aluminum
Surface: powder coated, RAL 9010

Product advantages

• Accepts accessories compatible with 25 x 10 mm standard rail according to DIN EN ISO 19054
• Height-adjustable standard rail
• Rear bracket allows attachment to bed frames and rails
• Self-centring suspension brackets
• Stable support due to rear bevelling

Characteristics / Technical specifications

• Article No.: 113-012
• Base (WxD): 400 x 250 mm
• Height: 390 mm
• Rear edge (WxD): 41 x 50 mm
• Rail profile (DIN EN ISO 19054): 25 x 10 x 390 mm
• Raster for standard rail: 50 mm
• Weight: approx. 2.4 kg
• Max. payload: 2 kg
• Material: aluminum
• Surface: powder coated, RAL 9010
