Transport trolley MS73203

wastestainless steelplastic

Product overview
This mobile waste collector is designed for two 70‑litre bags and fitted with 2 x CLAPPY clamping rings, an automatic brake, locking devices and a drill twister with chain for secure bag handling. Frame and fittings are suitable for industrial cleaning operations.

Key features

• 2 x CLAPPY for 70‑litre bags
• Automatic brake on pedal mechanisms
• 2 x locking devices for open position (hold-open)
• Frame: stainless steel, welded tube joints
• 2 x plastic trays: ABS
• Drill twister with chain (for bag closure)
• Castors: galvanized and chromium‑plated
• Tread: Ø 75 mm solid rubber, grey

Dimensions
Overall (L x W x H): approx. 1195 x 490 x 975 mm

Technical specifications

• Article number: MS73203
• Intended bag size: 70 litres (2 ×)
• Frame material: stainless steel
• Tray material: ABS (2 trays)
• Brake: automatic (pedal mechanisms)
• Locking: 2 hold-open locking devices (MSZ 011)
• Drill twister: MS 02 K (with chain)
• Castors finish: galvanized and chromium‑plated
• Tread diameter: 75 mm, solid rubber, grey
• Overall dimensions (L x W x H): approx. 1195 x 490 x 975 mm

Included

• 2 CLAPPY clamping rings for 70 L bags
• 2 pedal mechanisms with automatic brake and hold-open locking (MSZ 011)
• 1 drill twister with chain (MS 02 K)
• 2 plastic trays (PW 43/73)
• 4 bump protection discs (SP 31)
• 4 swivel castors Ø 75 mm, solid rubber
