Orthopedic trocar Disposable Orthopedic Trocar

with sleevewith insufflation tapsingle use

Introduction
Disposable orthopedic trocar designed to establish a secure port of entry for endoscopic and arthroscopic instruments during minimally invasive orthopedic procedures.

Specifications

• Sizes: Φ6.5/8.5 × 70/90/110 mm
• Materials: medical-grade PC (polycarbonate) and ABS
• Threaded cannula/sleeve available in diameters 6.5 mm and 8.5 mm and lengths 70 mm, 90 mm, 110 mm
• Integrated sealing system and Luer stopcock valve

Features

• Conical obturator tip minimizes incision size
• Visualized cannula with threaded design for stable placement
• Luer stopcock valve for controlled insufflation and desufflation
• Sealing system maintains insufflation during instrument exchange

Clinical information

• Indication: establish a port of entry for endoscopic instruments in minimally invasive arthroscopic procedures
• Compatibility: standard arthroscopy instruments and insufflation systems
• Single-use device; follow local sterilization and disposal protocols
• Available configurations: diameters 6.5 mm, 8.5 mm; lengths 70 mm, 90 mm, 110 mm
