Clinical ventilator SIARETRON 1000

medicalfor hyperbaric chambersnon-invasive

The new generation of the lung ventilator SIARETRON 1000 IPER is designed and certified for use in hyperbaric pressure chambers of up to 60 m water depth (6 bar chamber pressure). It can be used for adults, children and newborns. All ventilation parameters, such as minute volume/flow and rate, can be adjusted according to the physiology of the patient. Functions of the ventilator: Safety valve protected expiration line Breathing gas mixer (21% to 100% oxygen, as well as HELIOX mixtures (premixed)) Standard connections for patient hose systems Electrical connection: Pressure-proofed accumulators and/or medical electrical power supply Technical details: Ventilating mode: Time-controlled with constant volume or pressure-controlled Controlled and compensated flow Display for visualization of relevant parameters (loops, curves, measured values, etc.) Spontaneous breathing through integrated valve Gas supply: Compressed, medical air and oxygen (or premixed HELIOX) with a supply pressure of 4 bar (±0.75 bar) above chamber pressure
