Muffle furnace FNC-TB1700 series

for ceramicshigh-temperaturebenchtop

1700°C maximum operating temperature; PID automatic control via current limiting phase angle fired the resistor, e.g. SC R (Silicon Controlled Rectifier); 30 or 50 segments “time-temperature curve” can be set arbitrarily. Tube furnace using high purity quartz or alumina tube as a furnace tube, furnace tube design with horizontal installation, vertical installation. Temperature zone is designed with single-zone, dual-zone, three-zone, five-zone and so on. Furnace also increase the rotational tilt system. Safety Double layer steel structure with air cooling fan to keep furnace’s exteriors safe to touch; Safety interlock with automatic power off the furnace when door is opened(optional) Optional Different chamber size for your choose. Touch screen (with USB interface) Computer connection software, control equipment (RKC, 16-segment program + interface + software)
