Electric wheelchair ECO

for disabled peopleoutdoorindoor

Overview
The ECO electric wheelchair is designed for daily mobility, travel and rehabilitation. It combines a foldable, portable frame with a simple operation to support user independence and caregiver handling in clinical and home-care settings.

Key Properties

• Footrest: Detachable footrest
• Seat and Backrest: Nylon
• Front Fork: Plastic
• Footplate: Plastic
• Special: Simple backrest half folding
• Seat Width: 46cm
• Seat Depth: 40.5cm
• Weight Capacity: 100kg

Product Features

• Durable wheels suitable for indoor/outdoor use
• Detachable and adjustable footrest for patient comfort
• High-quality steel frame for stability
• Foldable backrest for compact storage and transport

Packaging

• 180 pcs / 20GP, 477 pcs / 40HQ (22")
• 170 pcs / 20GP, 378 pcs / 40HQ (24")

Specification
Overall Length (cm): 92/102/98
Overall Width (cm): 60/63/63
Overall Height (cm): 91/99/95
Carton Size (cm): 95*60*70
Overall Width Folded (cm): 23/26/25
Back Height (cm): 45/45/45
Floor to Seat Height (cm): 46/53/46.5
Front Caster Spec: 6"/8"/6"
Rear Wheel Spec: 22"/24"(MAG)/24"(spoke)
G./N. Weight (kg): 15.5/13.5; 17.5/15.0; 17.0/15.0
Carton Size (cm): 71*24*74 / 78*27*81.5 / 78*27*79

Technical specifications

• Model name: ECO
• Type: Electric wheelchair (foldable, lightweight)
• Seat & back material: Nylon
• Frame: High-quality steel frame
• Footrest: Detachable, adjustable; footplate material: Plastic
• Front fork material: Plastic
• Seat width: 46 cm
• Seat depth: 40.5 cm
• Floor to seat height: 46 / 53 / 46.5 cm (variants)
• Overall dimensions (L/W/H cm): 92/60/91 ; 102/63/99 ; 98/63/95 (variants)
• Front caster spec: 6" / 8" / 6" (variants)
• Rear wheel spec: 22" / 24" (MAG) / 24" (spoke)
• Gross/Net weight (kg): 15.5/13.5 ; 17.5/15.0 ; 17.0/15.0 (variants)
• Packaging options (pcs per container): 180 (20GP) / 477 (40HQ, 22") ; 170 (20GP) / 378 (40HQ, 24")
• Maximum weight capacity: 100 kg
