Hospital bed backrest A20-H

positioningstainless steelelectric

Product Overview
The A20-H is an electric backrest unit for hospital and home-care beds, designed for intensive care and heavyweight users. It integrates a reinforced full-size steel frame and dual high-torque silent motors to support a rated load of 120kg. The unit provides backrest adjustment from 3° to 75° and leg raise from 0° to 40°, with a 1900mm integrated mattress length to maintain ergonomic continuity.

Key Features

• 120kg rated load: reinforced base steel and push rod thrust for stable operation under heavy users.
• Dual-motor system with synchronous and asynchronous control options.
• Backrest angle 3°–75° for reclining to seated positions suitable for feeding and self-care.
• Leg raise 0°–40° to improve circulation and reduce sliding during prolonged rest.
• 1900mm full-length mattress integration for continuous support and improved center-of-gravity stability.
• Full-size corrosion-resistant steel frame with industrial coating for durability against corrosion and deformation.
• Available widths: 750 mm, 830 mm, 900 mm to fit common single and double beds.
• Thickened folding auxiliary handrails to assist safe transfers and mobility.

Details

• Dual high-performance linear actuators enable independent adjustment of back and legs; coordinated posture distribution reduces pressure on hips to help prevent pressure injuries and slippage.
• Structural optimization of scissor lift mechanism and increased motor thrust ensure stable, low-vibration movement under full load across the full adjustment range.
• 1900mm integrated pad with rear anti-slip limiter maintains ergonomic continuity and secures pad position for load-bearing redundancy.
• Low-noise operation using German-engineered silent motors suitable for clinical and home-care environments.

Technical specifications

• Model: A20-H
• Rated load: 120 kg
• Backrest adjustment: 3°–75°
• Leg raise range: 0°–40°
• Mattress length: 1900 mm
• Available widths: 750 mm, 830 mm, 900 mm
• Frame material: Reinforced full-size corrosion-resistant stainless steel
• Drive: Dual-channel high-torque silent motors (120 kg class)
• Accessibility: Multi-level folding armrests, rear anti-slip guardrail
• Control: Ergonomic wired remote control
