Dimensions:L2240*W1060*H500mm
Bed platform:1980*900mm
Backrest adjustment: 0-75°±5°
Legrest adjustment: 0-45°±5°
Traction Shelf: 2023*793*1503mm
Traction Shelf Height: 1780-2020±10mm
Material:
1. Bed platform, structure and leg are all made of premium cold-rolled steel with electrostatic powder coating
2. The Bed platform consists of four foldable sections, a stamping frame
3. Detachable HDPE bed headboard and footboard, four corner bumpers are for bed protective
4. Four-section full-length protection HDPE side rails operated by gas spring
5. Orthopedics Traction shelf is made of molding aluminum alloy
Standard Features:
1. Manual Three functions: Backrest adjustment 0-75°±5°; Legrest adjustment 0-45°±5°
2. Blue liquid angle indicator on backrest and legrest side rails
3. Clear acrylic bedside card for patient name display, Four infusion holes, two drainage hooks around the bed
4. Mechanical crank operation with overload protection
5. The screw handle is foldable under the bed footboard
6. Four 125mm diameter castors with central brake
7. Orthopedics Traction shelf is made of molding aluminum alloy 2023*793*1503mm
Optional accessories:
I.V. Pole, Mattress, Bed shelf
