Overhead laboratory mixer STR41-20

digitalfor the pharmaceutical industryfor drug development

Product Details
Laboratory overhead stirrers are designed for the safe and effective mixing of large volumes of liquids. It guarantee best mixing results through its self-reinforcing flow characteristics. Ideal for all mixing applications in the laboratory. Quality, performance and reliability are the best features that makes it unique.

• Used in: Chemical Synthesis, Medical, Pharmaceutical Synthesis, Physical analysis, Laboratory, Chemical Analysis, Petrochemical Industry, Research, Pharmaceutical
• Also known as: Flange mounted vertical stirrer, Mechanical stirrer, Laboratory Overhead stirrer, Laboratory Flange mounted vertical stirrer, Laboratory Mechanical stirrer, Digital Overhead Stirrer

Key Features

• LCD display set and actual speed.
• Torque trend display for real-time information on viscosity changes.
• Stirring paddle top-cross design, easy to replace the container.
• Brushless DC motor for long life, maintenance free.

Features

• LCD display set and actual speed.
• Torque trend display for real-time information on viscosity changes.
• Stirring paddle top-cross design, easy to replace the container.
• Brushless DC motor for long life, maintenance free.
• Start/run smoothly, prevent sample splatter or overflow.
• Multi-purpose, multi-specification high quality stainless steel, PTFE stirring paddle optional.
• Remote function provide PC control and data transmission.
• Safety circuits allow for safe stop function in anti-spill or overload conditions.
• Provides a constant speed even with changes in viscosities of the sample.

Specifications
Max. stirring quantity [H 2 O]: 20 L
Torque display: LCD
Max. torque: 40 Ncm
Speed display accuracy: ±3 rpm
Overload protection display: LED lights
Viscosity max.: 10000 mPas
Chuck range diameter: 0.5-10 mm
Data connector: RS232
Speed range: 50~2200 rpm
Temperature: 5-40°C
Maximum Temperature: 0.8
Heating Warning: 50
Heating Output: Brushless DC motor
Protection Class: IP21
Overall Dimension: 83Wx220Hx186D mm
Optional Accessories: 2.8 kg
Power: 70 W
Power Supply:

Caractéristiques / spécifications techniques

• Model: STR41-20
• Max. stirring quantity: 20 L
• Torque display: LCD
• Max. torque: 40 Ncm
• Speed display accuracy: ±3 rpm
• Overload protection display: LED lights
• Viscosity max.: 10000 mPas
• Chuck range diameter: 0.5-10 mm
• Data connector: RS232
• Speed range: 50~2200 rpm
• Temperature range: 5-40°C
• Protection Class: IP21
• Overall Dimension: 83Wx220Hx186D mm
• Weight: 2.8 kg
• Power: 70 W
