Laboratory freezer Versafreeze VF 15040

for drugsbuilt-inupright

Overview
LAUDA Versafreeze VF 15040 is an ultra-low temperature upright laboratory freezer designed for long-term storage of pharmaceutical products, biological samples and temperature-sensitive materials. It features a modern touchscreen, password-protected user management and optional secure remote monitoring via LAUDA Cloud for location-independent control of critical values.

Key features

• Working temperature range -40 … 0 °C with high temperature uniformity
• Usable volume: 129 L; interior completely made of stainless steel with 3 stainless steel drawers
• Vacuum-insulated panels and side-blown cooling coils for fast cooldown and uniform temperature distribution
• Energy-efficient, maintenance-free refrigeration system with hermetic high-performance compressors
• 4.3-inch touchscreen control with digital display and adjustable high/low alarm limits
• Password-protected access rights and electronic alarm with potential-free contact
• Built-in data logger for temperature and alarm recording; IIOT-ready via Ethernet and RS485 options
• Two 13 mm lead-throughs for external sensors (e.g. Pt100)
• Battery-backed display and alarm functions; magnetic door seals and stainless steel handles
• Can be installed freestanding or built under a workbench for laboratory integration

Working range
Min. working temperature: -40 °C
Max. working temperature: 0 °C

Applications
Long-term storage and quality assurance of organic substances, pharmaceutical products, biological samples and other temperature-sensitive materials. Designed for secure monitoring and integration into plant control systems.

Technical specifications

• Usable volume: 129 L
• Inner dimensions (W×D×H): 480 × 480 × 560 mm
• Overall dimensions (W×D×H): 904 × 776 × 865 mm
• Temperature stability: ±2 K
• Cool down time: 20 °C to -40 °C in 5 h
• Thaw time: -40 °C to 0 °C in 12 h
• Ambient temperature range: 15 … 28 °C
• Power supply: 230 V; 50 Hz; power cord with angled plug (CEE7/7)
• Weight: 128 kg
• Refrigerant: environmentally friendly natural refrigerants
• Part no.: L003540
