Velcro® tourniquet Rayband

manualfor general care

Overview

• Coronary drug-coated balloon catheter designed to deliver paclitaxel to inhibit restenosis; indicated for in-stent restenosis, small vessel disease and bifurcation lesions.

Structure and technical parameters

• Effective catheter length: 135 cm
• Compatible guidewire: 0.014''
• Balloon type: semi-compliant; platinum markers at each balloon end
• Delivery system: rapid-exchange balloon catheter with spiral-cut hypotube transition

Antiproliferative drug

• Drug: Paclitaxel — highly lipophilic with long half-life; drug loading: 3 µg/mm; drug loading matrix: urea for biocompatibility and controlled release; coating particle size 2–3 µm; in vivo release rate >90%.

Product features

• Urea-based coating enables effective paclitaxel release and improved biocompatibility
• Improved PEBAX material reduces crossing profile and increases flexibility
• Spiral-cut hypotube strengthens the transition section and optimizes deliverability
• Semi-compliant balloon improves crossability and facilitates retraction
• Efficient drug transfer: ~98% of paclitaxel reaches the lesion site before dilatation; ~90% released during dilatation

Ordering information (diameter → length : product code)
Diameter /mm — Length (mm): 9, 12, 16, 20, 24, 28, 31, 35, 38
2.0 — LPCDB 20009, LPCDB 20012, LPCDB 20016, LPCDB 20020, LPCDB 20024, LPCDB 20028, LPCDB 20031, LPCDB 20035, LPCDB 20038
2.5 — LPCDB 25009, LPCDB 25012, LPCDB 25016, LPCDB 25020, LPCDB 25024, LPCDB 25028, LPCDB 25031, LPCDB 25035, LPCDB 25038
2.75 — LPCDB 27009, LPCDB 27012, LPCDB 27016, LPCDB 27020, LPCDB 27024, LPCDB 27028, LPCDB 27031, LPCDB 27035, LPCDB 27038
3.0 — (9 mm not available), LPCDB 30012, LPCDB 30016, LPCDB 30020, LPCDB 30024, LPCDB 30028, LPCDB 30031, LPCDB 30035, LPCDB 30038
3.5 — LPCDB 35009, LPCDB 35012, LPCDB 35016, LPCDB 35020, LPCDB 35024, LPCDB 35028, LPCDB 35031, LPCDB 35035, LPCDB 35038
4.0 — (9 mm not available), LPCDB 400012, LPCDB 400016, LPCDB 400020, LPCDB 400024, LPCDB 400028, LPCDB 400031, LPCDB 400035, LPCDB 400038
4.5 — LPCDB 45009, LPCDB 45012, LPCDB 45016, LPCDB 45020, LPCDB 45024, LPCDB 45028, LPCDB 45031, LPCDB 45035, LPCDB 45038

Indications

• Stent restenosis
• Small vessel disease
• Bifurcation lesions

Technical specifications

• Product name/line: Vesselin Drug Coated Coronary Balloon Catheter
• Effective catheter length: 135 cm
• Compatible guidewire: 0.014''
• Antiproliferative drug: Paclitaxel
• Drug concentration/loading: 3 µg/mm
• Drug loading matrix: Urea
• Markers: Platinum at each balloon end
• Delivery system: Rapid-exchange; spiral-cut hypotube transition
• Balloon type: Semi-compliant
• Coating particle size: 2–3 µm
• Typical indications: stent restenosis, small vessel disease, bifurcation lesions
