Monitoring ECG cable Eel Cath™

4-wire

Product description
The Eel LPEPC series electrophysiology catheter cable connects diagnostic and ablation catheters to compatible electrophysiology recording and ablation systems. It is compatible with Johnson & Johnson and St. Jude equipment and is offered in multiple catalog variants to match different cable diameters, lengths and numbers of output terminals.

Features

• Redel proximal connector
• Designed for use with temperature-controlled catheters
• Color-coded distal connection lines for easy identification
• Available in diagnostic and ablation configurations

Ordering Information - Diagnostic Catheter Cable
Catalogue No. | Cable Diameter (mm) | Cable Length (cm) | Output Terminal Cable Diameter (mm) | Number of Output Terminals
LPEPC(0104) | 6.2 | 200 | 3 | 4
LPEPC(0110) | 6.2 | 200 | 2 | 10
LPEPC(0112) | 6.2 | 200 | 2 | 12

Ordering Information - Ablation Catheter Cable
Catalogue No. | Cable Diameter (mm) | Cable Length (cm) | Number of Output Terminals
LPEPC(0210) | 4.5 | 250 | 10
LPEPC(0214) | 4.5 | 250 | 14

Technical specifications

• Series: LPEPC (0104, 0110, 0112, 0210, 0214)
• Compatibility: Johnson & Johnson catheters & equipment; St. Jude equipment
• Connector: Redel proximal connector
• Cable diameters: 6.2 mm (diagnostic); 4.5 mm (ablation)
• Cable lengths: 200 cm (diagnostic); 250 cm (ablation)
• Output terminal cable diameters: 3 mm (LPEPC(0104)); 2 mm (LPEPC(0110/0112))
• Number of output terminals: 4, 10, 12 (diagnostic variants); 10, 14 (ablation variants)
• Color-coded distal lines for identification
• Intended use: connection of diagnostic and ablation electrophysiology catheters to recording/ablation systems
