Gynecological care training manikin Maya LST

obstetrical/gynecologicalmaternal/neonatal carefor obstetric care

Overview
Maya is an automated birthing simulator designed to teach labour, birth and postpartum care fundamentals. It combines the portability and simplicity of a task trainer with the realism and scenario-based learning of a full-body simulator, enabling standardised obstetric training without complex setup.

Automated Birth Simulation
Deliver repeatable, realistic births at the touch of a button. Automated fetal descent and delivery reduce facilitator workload and ensure consistent experience and rapid resets for increased hands-on practice.

App-Controlled Scenario Management
Configure and run scenarios via a user-friendly app. Adjust labour progression, fetal position and complications in seconds. The app supports multiple languages and logs trainee actions for exportable timelines.

Vaginal Examination Training

• Cervical dilation: 4–10 cm for labour assessment
• Fetal station: realistic anatomical landmarks
• Presentation: four interchangeable presenting parts (flexed head, deflexed head, indifferent head, breech)
• Fetal position: adjustable rotation of the baby model

Normal & Emergency Obstetric Scenarios

• Normal vaginal birth
• Vaginal breech birth
• Shoulder dystocia
• Assisted vaginal birth (forceps and vacuum)
• Third stage complications
• Postpartum haemorrhage (PPH)

Quantitative Blood Loss (QBL) Measurement
Integrated Clean Bleed Mat supports realistic PPH scenarios with up to 2.5 litres simulated blood to train and assess QBL.

Designed for Independent Learning
Maya's intuitive setup and automation allow learners to practise independently, reducing facilitator dependence and expanding access to simulation-based education.

Skills and Procedures Supported

• Normal vaginal birth and vaginal breech birth
• Shoulder dystocia management
• Assisted vaginal birth (forceps, vacuum)
• Vaginal examination (dilation, station, presentation, position)
• Labour progression assessment
• Third stage management, placental delivery and retained placenta removal
• Fundal massage and PPH management
• Urinary catheterisation and intramuscular injection
• Communication, teamwork and escalation when used with a simulated patient

Highlights / Key Features

• Automated, realistic cephalic and breech deliveries
• Attachable lower legs for varied birthing positions and portability
• Automated vaginal exam with four presenting parts and 4–10 cm dilation
• Programmable obstetric emergency scenarios including shoulder dystocia and assisted birth
• Realistic baby model with spinal flexion, palpable landmarks and articulating limbs
• Magnetic placental piece for retained placenta simulation and removal
• Built-in Clean Bleed Mat for PPH simulation
• Rapid reset times and minimal manual intervention

Realism

• Simulates breech, shoulder dystocia and assisted vaginal births
• Clean Bleed Mat replicates PPH for QBL calculation

Versatility

• Approximately 8-hour internal battery life; also operable from mains
• Pre-set and customisable scenarios via app
• Detachable lower legs for transport and varied positions
• Suitable for skills labs, classrooms, simulation centres and clinical training

Anatomy & Simulated Patient Use

• Female lower body manikin: mid-chest to thighs, detachable lower legs
• Baby model with placenta and umbilical cord; palpable anatomical landmarks
• Designed for use with a simulated patient to train patient-practitioner interaction

Cleaning & Safety

• Remove excess lubricant and wipe surfaces with a soft damp cloth, warm water and mild detergent; dry before storing
• Latex free
• Contains electronics — do not submerge
• Wear gloves when handling and avoid sharp objects to protect silicone
• Lift using carrier handles only

Comparison
Maya — Other Birthing Simulators on the Market
Easy set up — Complex set up
Low maintenance — Higher maintenance
Designed for use with a simulated patient — Full-body manikins limit practitioner/patient interaction
Includes tech tools for labour customisation and automation — Reliant on manual control
Full articulated legs for realistic scenarios — Limited leg designs
Supports complete and partial placental delivery — Add-on or limited options
PPH included via Clean Bleed technology — PPH not supported or requires extra module
Focus on stages 1–3 of labour and PPH management — Focus on emergency management during birth
Detachable legs for portability — Full-body manikins suited to permanent placement

Why Choose Maya?

• Consistent training outcomes via automated births
• Increased hands-on practice with rapid resets
• Reduced facilitator burden so educators focus on feedback
• Intuitive operation and portable deployment

Skills Gained

• Management of normal delivery, breech, shoulder dystocia and assisted birth
• Vaginal examination skills (station, dilation, presentation, position)
• Fundal massage, placental delivery and retained placenta management
• QBL measurement and PPH management
• Urinary catheter placement and IM injection technique
• Patient communication, teamwork and escalation with a simulated patient

Evidence & Application
Maya supports undergraduate teaching and multidisciplinary team training by delivering repeatable, standardised obstetric scenarios aligned with curricula and competency frameworks.

Specifications

• Model / commercial name: Maya LST (Maya)
• Automated vaginal exam with 4 presenting parts; dilation 4–10 cm
• Supports cephalic and breech deliveries; programmable complications including shoulder dystocia and assisted birth
• Integrated Clean Bleed Mat supporting up to 2.5 litres simulated blood for QBL
• Baby model with placenta, umbilical cord, articulating limbs and palpable landmarks
• Magnetic placental piece for retained placenta simulation
• Female lower body manikin: mid-chest to thighs; detachable lower legs
• Power: internal rechargeable battery (~8 hours) or mains operation
• Control: app-controlled via Bluetooth; app available for Android and Apple tablets
• Latex free
• Portable with rapid reset times
