STRUCTURE:
Epoxy-coated steel tube frame.
Scissor - lift raising system for greater stability and loads of up to 150 kg.
Complete with lateral bars for accessories.
Extensive laboratory testing ensures that the Diamed Pro chair combines ergonomics with high levels of comfort in order to improve the patients’ health and quality of care.
Useful surface: 100%.
HANDLING:
Platform profiling by means of low-voltage electric motors compliant with EN 60601-1.
Electric adjustment of height, backrest and knee by means of a handset.
Electrically adjustment for Trendelemburg position up to 22º.
Handset designed to allow easy and quick positioning of the chair sections.
Four 125 mm diameter swivel castors (two brake castors, two freewheeling castors) ensure easy maneuverability of the chair.
High-density polyurethane foam backrest and seat for optimum comfort and ergonomic adaptability.
Upholstered with antibacterial, abrasion-resistant, M-1 class self -extinguishing vinyl. Easy to clean and maintain.
Steel side rails with height adjustment. Arm supports made in injected polyurethane (PUR).
Diamed Pro Chair is manufactured under UNE standard 93/42/CEE.
Electric features:
Electric feed: 100-240V 50-60 Hz
Maximum consumption: 3,15 A
Protection Indicator: IPX4
Class of protection :Class II
Level of protection: Type B.
Technical Data:
External dimensions: 192 x 91cm.
Patient surface: 1,92 x 59 cm.
Backrest dimensions: 59 x 83cm.
Pelvic area dimensions: 59 x 52cm.
Legrest dimensions: 59 x 58,5cm.
Height adjustment: 65-81,5cm.
Backrest tilting: 68º
Trendelemburg: 22º/0º
Maximum weight loaded: 150kg.
Weight without accessories: 45kg.
