Polysomnograph with SpO2 monitoring

with EMG monitoringwith NAF monitoringwith EOG monitoring

Key Features

• Upgraded wearing experience — non‑invasive, high conformity: High‑elastic flexible electrodes provide non‑invasive contact with the skin, reducing discomfort associated with rigid electrodes and improving patient compliance for prolonged monitoring.
• Full coverage of sleep gold‑standard signals: Continuous acquisition of EEG, EOG, submental EMG, oronasal airflow, ECG and SpO₂, delivering data dimensions consistent with hospital‑grade monitoring to support comprehensive diagnosis.
• Wireless transmission for hospital and home use: Multi‑standard wireless connectivity (5G/Bluetooth dual‑mode + Wi‑Fi) eliminates cable constraints and enables accurate monitoring across clinical and home scenarios.
• AI + manual dual analysis for accuracy and efficiency: Integrated sleep deep‑learning model achieves sleep staging accuracy >90% by multi‑modal signal fusion; automatic analyses include sleep trends, respiratory events and oxygen desaturation, with manual review capabilities to ensure diagnostic reliability.

Technical Specifications
EEG, EOG and EMG Sections
Standard signal amplitude accuracy: 25μV, 50μV, 100μV, 200μV, 1mV (error tolerance ≤ ±10%)
Sensitivity: 10μV/cm (error tolerance ≤ ±10%); 20μV/cm ～ 2000μV/cm (error tolerance ≤ ±5%)
Amplitude‑frequency characteristic: EEG 0.5Hz ~ 50Hz; EOG 1Hz ~ 5Hz; EMG 30Hz ~ 100Hz; error range −30% ≤ Error ≤ +5%
Polarization voltage withstand: ±300mV DC | Sensitivity variation ≤ ±5%
Input impedance: ≥1000 MΩ

ECG Section
Standard signal amplitude accuracy: 1mV (error tolerance ≤ ±10%)
Amplitude‑frequency characteristic: 1Hz ~ 25Hz; error range −30% ≤ Error ≤ +5%
Polarization voltage withstand: ±300mV DC | Sensitivity variation ≤ ±5%
Input impedance: ≥1000 MΩ
Sensitivity settings: 5, 10, 20 mm/mV (deviation ≤ ±5%)

SpO₂ Section
Display range: 50% ~ 100%
Measurement range and accuracy: 85% ~ 100%, absolute error ≤ ±2%; 70% ~ 85%, absolute error ≤ ±3%

Pulse Rate Section
Display range: 25–250 bpm
Measurement accuracy: error ≤ ±3 bpm

Thoracic / Abdominal / Naso‑oral Airflow Section
Frequency range: 0.1Hz ~ 1Hz; error range −30% ≤ Error ≤ +5%

Advantages

• Flexible sensing resolves discomfort and signal distortion associated with rigid electrodes.
• Wireless multimodal collaboration enables seamless hospital‑to‑home monitoring workflows.
• AI large‑scale model combined with manual review increases processing efficiency and diagnostic accuracy while reducing specialist workload.
• Optional HD infrared real‑time observation supplements physiological data with behavioral monitoring during sleep.
• Disposable dedicated electrodes available for rapid primary screening and stable signal acquisition.

Service & Support
Comprehensive lifecycle support delivered through a global technical assistance framework to maximize system uptime and ensure operational continuity.

Characteristics / Technical summary

• Wireless transmission modes: 5G / Bluetooth (dual‑mode) + Wi‑Fi for cable‑free clinical and home monitoring.
• Sleep AI model staging accuracy: >90% (multi‑modal signal fusion); supports automatic analysis of sleep trends, respiratory events and oxygen desaturation plus manual review.
• EEG standard signal amplitude accuracy: 25μV to 1mV (±10% tolerance); amplitude‑frequency: 0.5Hz–50Hz.
• EEG input impedance: ≥1000 MΩ; polarization withstand ±300mV DC; sensitivity variation ≤ ±5%.
• ECG standard signal accuracy: 1mV (±10%); amplitude‑frequency: 1Hz–25Hz; sensitivity settings 5/10/20 mm/mV (deviation ≤ ±5%).
• SpO₂ display range 50%–100%; accuracy: ≤ ±2% at 85%–100%, ≤ ±3% at 70%–85%.
• Pulse rate range: 25–250 bpm; accuracy: error ≤ ±3 bpm.
• Respiratory signal frequency range for thoracic/abdominal/naso‑oral airflow: 0.1–1Hz (error −30% to +5%).
