Ventilation Modes:
NCPAP, NIPPV, SNIPPV, HFNC
Main Specifications:
8 inch, TFT, Touchable
Fully Electronic Air and Oxygen Mixer Mode
Apply to respiratory support required prematüre, neonate and child under 30 kg
Fully electronic control of air-oxygen blending,one key setting, provide max120s oxygen ventilation
Pressure accuracy ± 2%, volüme accuracy ± 5%
Support low-volume ventilation, min volüme:0.5 L/Min
Fresh gas Flow range: 0L/min-40L/min
Display: Pressure-Time wave, Flow bar graph
Monitoring Parameters: Pressure (Peak airway Pressure, Mean Pressure, PEEP, Airway Pressure), Oxygen concentration, Flow, Spon Rate, Expiratory Time, I:E
Fresh Air: O2 and Atmosphere
O2% : 21%-100%
Fast O2% : 23%-100%
Auto Leakage Compensation
Alarm Delay : 1s-10s
