Keyboard with numeric keypad P-M272-BL

with international layoutsiliconeLED-backlit

Product Overview
A ROHS-certified medical silicone keyboard designed for clinical and industrial environments. Model P-M272-BL with 88-key layout including numeric keypad, adjustable blue backlight and USB wired interface. IP68 rated for waterproof and washable operation. Available in white or black with OEM logo option.

Main Features

• IP68 waterproof and washable construction; silicone top with chemical-resistant coating
• 88 keys including numeric keypad and integrated function keys; sealed design for gapless cleaning
• Adjustable blue LED backlight for low-light use; low power consumption (30 mA without backlight, 150 mA with backlight)
• Comfortable, low-noise typing with carbon-on-gold switch technology and gold PCB
• USB wired communication with 1.8 m cable; compatible with Windows layouts and multiple languages
• Compact dimensions (275 x 136 x 12 mm) and robust operating range (-30°C to +70°C)

Technical specifications

• Model: P-M272-BL
• Material: Silicone with durable chemical-resistant coating
• Key count: 88 keys (includes numeric keypad)
• Interface: USB, 1.8 m cable
• Backlight: Blue, adjustable brightness
• Protection: IP68 (waterproof & washable)
• Certifications: CE, FCC, ROHS
• EMC/EMS standards: IEC61000-4-2:2008; IEC61000-4-3:2006+AI:2007+A2:2010; IEC61000-4-4:2004; EMI: EN55022:2010; EMS: EN55024:2010
• Supply Voltage: +5V DC ±5%
• Current consumption: 30 mA (no backlight) / 150 mA (backlight on)
• Switch technology: Carbon-on-Gold key switch with gold PCB
• Lifespan: >3 years
• Dimensions: 275 x 136 x 12 mm
• Weight: 700 g
• Operating Temp: -30°C to +70°C
• Storage Temp: -40°C to +80°C

Certifications & Compliance

• CE, FCC, ROHS certified
• Meets listed EMC/EMS and EMI standards for use in medical and industrial environments

Ordering & Logistics

• Place of origin: Made in China
• Minimum Order Quantity: 1 pc; Price: Negotiable
• Packaging: inner box plus outer carton — 20 units per carton (carton size 43 x 38 x 32 cm)
• Delivery time: 1–2 weeks; Supply ability: 3000 pcs per month
• Payment terms: TT, PayPal, Western Union
