Automatic hematology analyzer PKL PPC 1100H

benchtop5-part differentiationflow cytometry

PKL PPC 1100H Auto Hematology Analyzer uses helium- neon laser for the flow cytometry system. Through calculations of different angles via laser scatters, the instrument provides complete analysis including cell size, granularity and complexity. One channel give complete differentiate WBC PKL PPC 1100H counts lymphocyte, monocyte, neutrophil, eosinophil and basophil in WOC channel. Sample Rotatory Valve (SRV) High precision Easy maintenance Blood sensormonitors aspiration volume Principles of operation WBC 5-part:Flow Cytometry(FCM)+ 4 angles laser light scatter WBC Analysis: Optical and impedance measurements RBC/PLT Analysis: Impedance method HGB test: Cyanide-free reagent colorimetry RET test: Flow Cytometry(FCM)+laser light scatter+Chemical dye method Reagent Diluent, Sheath, Detergent,Lyse Sampling device Automatic sampling device with a capacity of 120 samples,10 samplesX12 racks, auto built-in barcode reader PKL PPC1100H Auto Hematology Analyzer uses helium-neon laser for the flow cytometry system. Through calculations of different angles via laser scatters, the instrument provides complete analysis including cell size, granularity and complexity. Data storage Up to 200,000 sample results with grams Alarms Error messages Display PC display (17 inch color TFT) Power 220V,50/60Hz 600VA
