ENT surgery handpiece

laserdirectcurved

Product overview
Enhance surgical precision with the PIOON ENT laser handpiece. The system includes a 7-piece cannula set (working lengths: 10 cm, 13 cm, 20 cm) and accepts optical fibers from 200 μm to 600 μm via an SMA905 interface. Components are fully autoclavable and the handpiece features an ergonomic pencil-grip form factor for microsurgical control.

Clinical versatility (Applications)

• Otology & middle ear surgery: Shorter cannulas (10–13 cm) provide precise access within the external auditory canal for procedures such as cholesteatoma removal and delicate tympanic work.
• Rhinology & airway management: Extended cannulas (up to 20 cm) reach posterior nasal cavity and nasopharyngeal targets for turbinate reduction and obstructive tissue ablation.
• Pharyngeal & oral procedures: Angled cannulas facilitate tonsillectomy, excision of oral leukoplakia and scar band release with controlled thermal effect to preserve surrounding mucosa.

Product highlights

• 7-in-1 adaptive design: Seven interchangeable cannulas with varied lengths and curvatures to match surgical indications.
• Ergonomic pencil-grip handling: Lightweight, balanced handpiece for enhanced tactile feedback and reduced operator fatigue during microsurgery.
• Universal fiber compatibility: Accepts 200 μm–600 μm optical fibers via standard SMA905 connector.
• Simplified sterilization: All patient-contact components are autoclavable at 134°C; manufactured from medical-grade stainless steel.

Technical overview

• Cannula set: 7 pieces (multiple angles and lengths)
• Working lengths: 10 cm / 13 cm / 20 cm
• Fiber core range: 200 μm – 600 μm
• Interface: SMA905
• Sterilization: Fully autoclavable at 134°C
• Material: Medical-grade stainless steel
• Intended use: Minimally invasive diode laser procedures in ENT (otology, rhinology, pharyngeal/oral)

Technical specifications

• Product type: ENT laser handpiece system
• Cannula quantity: 7 interchangeable cannulas
• Cannula working lengths: 10 cm, 13 cm, 20 cm
• Fiber compatibility: 200 μm – 600 μm optical fibers
• Connector/interface: SMA905
• Sterilization method: Autoclavable components up to 134°C
• Materials: Medical-grade stainless steel
• Design features: Multiple curvature options, ergonomic pencil-grip form factor, lightweight and balanced
