Oxygen therapy hyperbaric cabin Petra

monoplace

Short description
Designed to provide enhanced visibility and comfort, Petra is a modular seated hyperbaric chamber available in 2.0 and 2.4 ATA versions with two panoramic windows and a front acrylic retractable door.

Key features

• Modular seated hyperbaric chamber with retractable front acrylic door and oversized panoramic windows for improved visibility and user comfort.
• Available pressure options: 2.0 ATA and 2.4 ATA (configurable).
• Wireless external/internal 10" touchscreen control with user-friendly automation (internal and external tablet/smartphone control). Dual 10" control (external / internal).
• Dual oxygen delivery systems: Built-In Breathing System (BIBS) and Free-Flow (mask or nasal cannula) powered by a high-power oxygen concentrator (20 LPM, 5.0 Bar) with optional chiller for temperature regulation.
• Ergonomic lounge seat (option: 1 recliner with foot support), adjustable LED RGB lighting, continuous ventilation, and eco-leather interior upholstery.
• Customizable exterior paint (over 170 RAL codes), accent finishes, interior lining, and seating options.
• Real-time monitoring of pressure, oxygen levels, speed, temperature, precise adjustments and session tracking; chamber operable without external assistance.
• Dual communication systems to maintain contact between user and operator throughout sessions.

Product Description
Petra is intended to provide improved visibility and comfort during hyperbaric sessions. Offered in 2.0 and 2.4 ATA versions, Petra features a retractable front acrylic door that facilitates access for users with limited mobility. Oversized panoramic windows reduce the sense of confinement and improve the user experience. The pressure vessel can be supplied in aerospace aluminum or steel. The automated control system is operable from an internal or external 10" touchscreen tablet or a compatible smartphone.

Oxygen is supplied via a 20 LPM, 5.0 Bar high-power oxygen concentrator through a dual-delivery configuration: BIBS (mask) and Free-Flow (mask or nasal cannula), removing the need for oxygen cylinders. An optional chiller is available to stabilize interior temperature during pressurization. Monitoring displays real-time pressure, oxygen concentration, temperature, session timing and allows precise adjustments. The chamber is designed to be used without external assistance when required.

The interior offers an ergonomic lounge seat, adjustable LED RGB lighting, continuous ventilation and eco-leather upholstery for a comfortable environment. Dual communication channels ensure continuous operator contact during therapy.

Petra's automation and customization options — exterior color, accent finishes, interior lining and seating choices — enable specification to facility design and user requirements.

System Features

• Dual Oxygen Delivery Systems: Switchable between BIBS mask and Free-Flow (mask or cannula).
• Built-In Breathing System (BIBS): Delivers oxygen on demand during inhalation via mask from a 20 LPM concentrator, reducing CO2 accumulation and supporting users with respiratory limitations.
• Free-Flow Oxygen Delivery: Continuous oxygen flow via mask or nasal cannula driven by a 20 LPM concentrator; simple and low-maintenance.
• High-Power Oxygen Concentrator: Provides 20 LPM at approximately 93% O2 at 5.0 Bar.
• Air Compressor: Inflates the chamber with filtered ambient air, maintains set pressure and performs decompression as required. Pressure and session duration controllable from interior or exterior interfaces.
• Chiller System: Controls interior temperature to offset pressure-related heating, ensuring occupant comfort.

Technical specifications

• Chamber Body — Material: Steel & Acrylic (options include aerospace aluminum or steel / acrylic).
• Chamber Dimensions (L x W x H): 158 x 208 x 195 cm.
• Max Pressure (configurable): 2.0 ATA | 2.4 ATA.
• Chamber Weight: 2.0 ATA - 900 kg | 2.4 ATA - 1100 kg.
• Modular Sections: 3.
• Oxygen Delivery (Dual): BIBS & Free Flow (mask or cannula).
• Control Tablet (Dual): External 10" / Internal 10" touchscreen.
• Module Functions: Customizable protocols, 2-way communication.
• Occupancy & Seating (option): 1 x recliner with foot support.
• Lighting: Adjustable LED RGB lights.
• Certifications Included: 2006/42/EC, 93/42/EEC (PED).
• Certifications Optional: ASME PVHO-1, UKCA, MEDICAL CE.
• Customization Options: Paint RAL (over 170 RAL codes), interior lining, lounge chair options (Modena or Polisoft).
• Compressor — Dimensions (L x W x H): 100 x 50 x 80 cm; Weight: 67 kg; Power: 4 HP; LPM Output: 564; Noise Level: 48 dB; Units Required: 1; Price: Included.
• Oxygen Concentrator — Dimensions (L x W x H) | Weight: 70 x 48 x 107 cm | 155 kg; Output: 20 LPM | ±93% O2 | 5 Bar; Power: 2500 W | 3.3 HP; Noise Level: ≤72 dB; Units Required: 1; Price: Extra.
• Chiller — Model: SMC Chiller (Japan); Cooling Capacity: 1 kW @ -10°C; Operating Range: -10°C to 40°C; Dimensions: 50 x 38 x 64 cm; Weight: 40 kg; Cooling Method: Air-cooled refrigeration; Price: Extra.
