Percutaneous external fixation system Fixor

adult

Description
Percutaneous stabilization system for meta-epiphyseal fractures treated with the guide-wire technique. Consists of stainless steel or titanium guide wires and an external radiolucent carbon-fiber plate equipped with screws to lock the wires. Guide wires in stainless steel or titanium are also available separately. Materials: stainless steel or titanium and carbon fiber. Stainless steel wires contain nickel; titanium wires are nickel-free.

Product variants

• FIXOR with 2 stainless steel guide wires 1.5 mm L = 150 mm — code FCX21215
• FIXOR with 2 stainless steel guide wires 2.0 mm L = 400 mm — code FCX22040
• FIXOR with 2 stainless steel guide wires 2.5 mm L = 400 mm — code FCX22540
• FIXOR with 4 stainless steel guide wires 2.5 mm L = 400 mm — code FCX42540
• FIXOR with 4 stainless steel guide wires 3.0 mm L = 400 mm — code FCX43040

Characteristics / technical specifications

• System: radiolucent fixator for percutaneous stabilization
• Technique: guide-wire treatment
• Components: guide wires, radiolucent carbon-fiber external plate, locking screws
• Materials: guide wires in stainless steel or titanium; external plate in carbon fiber
• Material properties: stainless steel wires contain nickel; titanium wires are nickel-free
• Available variants: 1.5 mm (L = 150 mm), 2.0 mm (L = 400 mm), 2.5 mm (L = 400 mm), 4 wires of 2.5 mm (L = 400 mm), 4 wires of 3.0 mm (L = 400 mm)
• Accessories: guide wires sold separately
