Multipurpose radiography flat panel detector 1012WCC·WGC

portablewirelesswaterproof

Reliable functionality considering user experience and convenience Illuminated OLED window indicates detector’s status Image preview time ≤ 2 sec Image storage : 3,600 Images High-reliability solution Advanced protection against the shock, vibration, scratch (Supporting up to 300kg) Equippted with user-friendly function Easy Sync : No need an electrical connection with generator Easy Drive : Acquired x-ray images can be viewed on any mobile device Specification Sensor Type a-Si TFT Scintillator CsI / GOS Total Pixel Matrix (Pixels) 2304 x 1792 Active Area (mm) 292.6 x 227.6 Pixel Pitch (㎛) 127 Frame Rate (fps) N/A (Static) Energy Range (kVp) 40 ~ 150 Resolution (lp/mm) 3.9 A/D Conversion (bits) 14 / 16 Data Interface GigE 802.11a/g/n/ac Dimension (mm) 328 x 268 x 15 Weight (kg) 1.8 (incl. battery)
