Laboratory evaporator Auto EVA Mini

for samplesfor microplatesparallel

Product overview
The Auto EVA Mini automated parallel nitrogen evaporator is designed for concentration of small-volume laboratory samples. It combines controlled nitrogen gas flow with programmable sample rack heating to deliver rapid, uniform evaporation for microplates and vials.
The unit accepts common microplates (96 shallow-well, 96 deep-well, 24- and 48-well). The 96-needle gas manifold ensures consistent flow distribution across wells. An optional heated nitrogen module accelerates evaporation for low-volume samples.
The related Auto EVA 80 model accommodates 2 mL GC vials and 1–2 mL centrifuge vials and is suitable for fast evaporation of QuEChERS purification extracts.

Key features

• Batch concentration for small-volume samples (microplates and vials)
• Precise and adjustable nitrogen flow control (0–3.0 L/min, 0.1 L/min resolution)
• Uniform gas distribution via 96 blowing needles
• Programmable sample rack heating: room temperature to 100°C (0.1°C resolution)
• 7-inch integrated touchscreen with graphical software control
• Compact footprint (47 × 25 × 43 cm), 21 kg; fume hood/ventilation required

Specifications

• Concentration method: Nitrogen blowing and sample rack heating
• Nitrogen channels: 4
• Sample capacity: 24 or 96 wells
• Compatible sample types: 2 mL / 5 mL centrifuge vials, 2 mL GC vials, 96-well microplates
• Flow rate range: 0–3.0 L/min (0.1 L/min resolution)
• Sample rack temperature range: Room temperature–100°C (0.1°C resolution)
• Nitrogen gas temperature range: Room temperature–70°C
• User interface: 7-inch built-in touch screen
• Dimensions: 47 cm × 25 cm × 43 cm; Weight: 21 kg
• Power: 200–240 V, 50/60 Hz; Power consumption: 1000 W
• Fume hood/ventilation: Required
• Storage: 0–40°C, 20–85% RH
• Operating environment: 10–40°C, 20–80% RH
