Service door STA 20

hospitalslidingglass

The Record STA 20 is a classic, well-proven single and double-leaf automatic sliding door system which can be installed as a complete door package, or retro-fitted on existing aluminium, steel or timber doors. With a unique learning ability to automatically adjust, the STA 20 offers outstanding reliability and ongoing performance. Key features Features Our classic single or double leaf sliding doors can be found where automatic doors are usually fitted. They have opening widths of 800 to 3 000 mm, and can accommodate door weights of up to 1 x 200 or 2 x 150 kilos. The record system 20 enables the construction of a vast range of door models. Designed using modular construction principles, it can be adapted to suit the widest range of conditions and yet is largely based on the same components. This shortens installation time and reduces service and maintenance costs. The record system 20 fulfils 2006 / 42 /  EG industrial guidelines for machines, DIN 18650 as well as meeting all relevant national and international norms and standards. Design For the record system 20, there are 20 mm thick aluminium profiles available for 10 mm thick single glazed leaves, or 32 mm thick profiles suitable for 24 mm thick insulating glass to allow the greatest possible transparency. Even profiles of other manufacturers up to 65 mm can be fitted. Both profiles and drive unit cover can be anodized or powder-coated. Drive unit heights for both the normal, DUO and RED versions are available in either 108 mm or 150 mm; 200 mm for the reinforced models. The drive unit can be fitted to the lintel, freestanding or integrated in the ceiling
