Intensive care ventilator DOL680A

clinicalanesthesiaelectronic

Microcomputer controlled,pneumatically driven and electronically controlled. Pressure, volume controlled treatment oxygen therapy machine. Simultaneously display for three waveforms and two loops Both Vti and Vte monitoring 100% oxygen fast system, make sure to provide pure oxygen at any time. 9inch TFT color screen display with Touch screen Multi safety mechanism for patient safety and three level colour coded audio-Visual alarms Medical Ventilator Breathing mode: VCV V-SIMV H-Flow PCV PSV P-SIMV SONT CPAP Demo Medical Ventilator Parameter Driven mode: pneumatically driven and electronically controlled Working mode: Pressure and volume FiO2:45～100％ Frequency： 1～150 bpm I：E 9.1:1~1：9.9 Hold%: 0～50％ Flow trigger:0.5-20 L/min Pressure trigger:-20-0 cmH2O Pressure control:0-60 cmH2O Freq_simv(bpm):2-60 P_insp(cmH2O)2-60 Pressure support:0-120 cmH2O Electronic PEEP:0-50 cm H2O Triggering sensitivity :-0.1～-2.0（OFF） KPa SIGH：1.0~2.0 VT/50 Inspiration Time: 0.1～12S Maximum inspiratory time：1.0～6.0 S Apnea time 3～12 S Inspiratory flow rate :5～120 L/min Wave form:P-T, F-T, V-T Loops:P-V, F-V Alarms Recall:1500Events Medical Ventilator Alarm parameters: Peak（cmH2O） high/low TV_Exp（ml） high/low Freq high/low FiO2 high/low PEEP(cmH2O) high/lowCircle Block High leak, Circuit disconnection, AC power failure, Low battery, Battery too low Alarm sound:0-10 grade T-Apneas(s):3-20S
