Heart vascular model F2394-X2.4

femoral arteryblood vesselscoronary arteries

Product overview
The 3D coronary artery model PLXG1001 is designed for interventional cardiology training, device testing and clinical procedure simulation. Manufactured in high-transparency food-grade soft silicone, it reproduces coronary anatomy and flow paths for realistic catheter, guide wire and stent handling in a controlled training environment.

Features

• Accurate anatomical dimensions and blood flow orientation for key vessels including thoracic aorta and left main artery, matching clinical coronary intervention scenarios.
• Main vessels cast in food-grade soft silicone with ≥90% transparency for clear visualization of device movement and deployment.
• Detachable chest/abdominal vessels with a flexible stenosis module for stent/balloon training and a hard rotational grinding module for rotational device training; supports customized aneurysm specifications.
• Dual access design (femoral and radial) compatible with clinical instrument pathways; optional pulse pump and temperature-controlled reservoir to simulate temperature, pressure, flow and pulse.

Supported instrument testing and surgical training
Compatible with testing and evaluation of guide wires, catheters, vascular stents, spring coils, thrombectomy stents and rotational grinders. Suitable for training in coronary angiography, aneurysm procedures, thrombectomy and coronary stenosis interventions. Custom aneurysm models for special device validation are available.

Material safety and observability
Main body made from food-grade soft silicone (hardness 30A) with material transparency ≥90%, enabling clear observation of device positioning, movement and implantation while maintaining realistic tactile feedback similar to human vessels.

Customization and supporting equipment
Customizable aneurysm models by vascular segment and size. Optional supporting devices: pulsation pump, temperature-controlled water tank and power supply (sold separately). Standard air transport boxes included to ensure safe shipment.

Comparison notes
Configurable base types: human-shaped shell base, acrylic shell base or illuminated base plate. Model variants (Coronary Training Model A/B/C) differ by heart shell material and pulsatile function when connected to pulse pumps.

Caractéristiques / spécifications techniques

• PN: PLXG1001
• Main material: Highly transparent soft silica gel, hardness: 30A
• Material grade: Food grade soft silicone, transparency ≥ 90%
• Model dimensions: Length 63 cm; Width 25 cm; Height 22 cm
• Detachable chest/abdominal vessels with flexible stenosis module and hard rotational grinding module
• Dual vascular access: femoral artery and radial artery
• Optional connections: pulse pump, temperature-controlled water tank to simulate temperature, pressure, flow and pulse
• Lead time: 15 days
• Origin: Shanghai, China
• Typical supported instrument tests: guide wires, catheters, vascular stents, spring coils, thrombectomy stents, rotational grinders
• Typical training applications: coronary angiography, aneurysm simulation, thrombectomy, coronary stenosis treatment
