1920 x 1080 OR video system iOR

3840 × 21604K1080p

Overview
Weyuan iOR System Solution is an open, vendor‑neutral integrated platform designed to provide real‑time visualization, device integration, digital documentation and workflow optimization for modern operating rooms. The solution supports clinical decision making, operational efficiency and clinician workflows for digital, smart and robotic OR environments.

Main benefits & functions

• Better visualization & decision‑making for surgeons
  • Real‑time integration of endoscopy, C‑arm, surgical field, ultrasound and vital signs
  • Flexible display layouts: PiP / PaP / quad‑view; single, dual or quad screen modes
  • Zero‑latency switching and template‑based view presets aligned with surgical phases
• Workload reduction for perioperative staff
  • One‑touch presets for images, lights and devices
  • Eliminates the need to adjust multiple systems during procedures
  • Real‑time device status display to improve efficiency and reduce communication errors
• Digital documentation & automatic archiving
  • Automatic generation of surgical report drafts, timestamps and recordings
  • Synchronization with HIS/PACS to minimize manual entry and improve accuracy
• Teaching, training & academic support
  • Real‑time 4K teaching and remote multi‑site interaction
  • Playback on mobile/tablet to support medical education and hospital academic activities
• Support for smart hospital and accreditation workflows
  • Data traceability, workflow visibility and integrated device management for digital/smart/robotic ORs

Instruction of main modules

• OR Image Management Module
  • Supports surgical audio/video interaction with preview before external live broadcast or recording
  • Control functions for external information output (ability to disable external output when required)
  • Capture and review functions for key surgical scenes; full procedure recording
  • Optimized image adjustment and control inside the OR
  • Digitization and remote transmission of video sources: surgical camera, panoramic/head camera, endoscope, ultrasound, patient monitor, vascular flow meter, patient data
  • Supports multiple simultaneous video input channels and high‑quality 4K recording
  • Operating room display control to route video signals and push any source to any display; supports flexible expansion
  • Capable of recording entire surgical procedures for process management
  • Recorded files can be stored on local servers or network storage (NAS/PACS)
• Operating Room Image Control and Transmission
  • Fiber‑optic AVoIP architecture for no‑latency, high‑speed image transmission
  • 4K60P high‑quality resolution
  • Supports display modes: single, dual, Picture‑in‑Picture (PiP), PoP, quad‑screen, with independent audio source selection
• Recording + Control System Assembly
  • Operating room image allocation and editing operations
  • Login system with account/password permission management
  • Four‑channel FHD synchronous recording or real‑time screen capture
  • Ability to add timestamps during recording for efficient search
  • Simultaneous recording of audio into video for complete surgical records
  • Receive signals from multiple medical devices and merge real‑time streams into a single video file
  • Supports screen switching functions (PiP, dual‑screen) and outputs integrated real‑time images to secondary displays in high quality

Technical specifications

• System type: Open, vendor‑neutral integrated iOR platform
• Supported video resolution: up to 4K (4K60P) and multi‑channel FHD recording
• Transmission architecture: Fiber‑optic AVoIP with zero‑latency switching
• Display modes: Single, dual, PiP, PoP, quad‑screen; PIP/PaP/quad layouts
• Input sources: Endoscope, C‑arm, surgical field cameras, ultrasound, patient monitor, vascular flow meter, panoramic/head cameras
• Recording: Four‑channel FHD synchronous recording, high‑quality 4K recording, timestamping, audio embedding
• Storage: Local servers or network (NAS/PACS) storage support; HIS/PACS synchronization
• User management: Account/password permission management
• Workflow features: One‑touch presets, device status display, template‑based view switching
• Use cases: Real‑time surgical decision support, perioperative workflow optimization, digital documentation, remote teaching and multi‑site interaction, integration with smart/robotic OR systems
