Display technology: TFT LCD (LED backlight)
Size of effective view (diagonal): - 611. 3mm (24.1 inch)
Aspect ratio :16:9
Resolution: 1920X1200
Dot pitch: - 0.270 x 0. 270mm
Color imaging: - Yes
Number of colors :16.70 million
Levels :100% ITU-R BT. 709 HD standard
Contrast :1000:1
Case color: White
Video input:
Composite video (lxBNC)
VGA (D-SUB)
3G/HD-SDI (lxBNC)
RGBS/YPbPr (4xBNC)
S“video (4 pin Mini DIN)
DVI-I single link (with HDMI)
RGBS/YPbPr (4xBNC)
S-video (4-pin mini DIN)
Video output: -
Composite video (lxBNC)
3G/HD-SDI (lxBNC)
Serial port control: RS-232 (D-sub p-pin)
Power supply (nominal) :AC 100-220V
Power supply management - Compliant with VESA DPMS and EPA power management
OSD language: - ChineseN English
Installation standard: Compilant with VESA DDCCi/2Bi standard
Work environment :0~50tlYl0%~90% no condensation
Storage environment - :-20~60lZ)/5%~90% no condensation
Calibration
EMC: EMC Médical
EMC standard: IEC60601-1-2, EN55011 /CISPR 11, FCC CFR47
IIEC60601 the 3rd édition
Certification/mark: CE, C-UL-US, DEMKO
Safety (médical device) : IEC60601-1, UL60601-1, CAN/CSA C22.2
No.60601-1-08
