Vaginal speculum GY0562

Weismansterilizable

Product overview
Weisman-Pederson Speculum is a double-bladed vaginal speculum with a screw-lock mechanism that maintains blade separation once inserted. Designed for clinical examination of the female genital tract, it is available in multiple blade sizes to suit different anatomies and procedures.

Variants / sizes

• Medium: 100 mm x 22 mm
• Large: 125 mm x 25 mm

Key features

• Smooth blade edges for atraumatic insertion and improved access.
• Screw-lock mechanism for hands-free operation during examination and minor procedures.
• Ergonomic handle profile for precise control and stability.

Materials & manufacturing
Manufactured from medical-grade German stainless steel. Components undergo passivation to enhance corrosion resistance. Supplied non-sterile; reusable and compatible with steam autoclave sterilization. Form, boiling and performance tests performed. Lifetime warranty against defects in materials and workmanship.

Product care
Correct cleaning and sterilization are essential for patient safety and instrument longevity. Recommended best practices include immediate point-of-use cleaning, thorough manual cleaning, validated mechanical decontamination, appropriate sterilization, complete drying, lubrication of moving parts and routine inspection. Specific guidance:

• Immediate cleaning at point of use; apply enzymatic sprays/gels/foams to prevent drying for heavily soiled instruments.
• Manual cleaning with soft brushes and approved detergents; pay attention to hinges, grooves and locking mechanisms; rinse with purified water.
• Use ultrasonic cleaners or automated washer-disinfectors for additional decontamination; arrange instruments according to equipment manufacturer instructions.
• Sterilization options: steam (autoclave), ethylene oxide gas, hydrogen peroxide plasma or dry heat according to instrument compatibility and manufacturer guidance.
• After gas sterilization, rinse instruments with purified water to remove residues.
• Ensure complete drying to prevent corrosion; use lint-free cloths or compressed air where appropriate.
• Apply only medical-grade, water-soluble lubricants to hinges/joints as recommended by the manufacturer.
• Inspect each instrument for cleanliness, structural integrity, operational function and wear; remove defective instruments from service.
• Package sterile instruments in appropriate pouches, wraps or rigid containers and label with sterilization date and contents.
• Store sterile instruments in a clean, dry controlled environment using first-in, first-out inventory management.
• Maintain detailed processing records, equipment logs, operator information and cycle monitoring results for traceability and compliance.

Usage & notes
The speculum is supplied non-sterile and must be cleaned and sterilized prior to clinical use. Available blade sizes accommodate a range of clinical cases. The screw-lock mechanism holds the blades open to allow hands-free examination and manipulation.

Technical specifications

• Model / Commercial name: Weisman-Pederson Speculum
• SKU / Article: GY0562
• Material: Medical-grade German stainless steel
• Sterility: Non-sterile (must be reprocessed prior to clinical use)
• Reusable: Yes
• Autoclavable: Yes
• Available sizes: Medium (100 mm x 22 mm), Large (125 mm x 25 mm)
• Locking mechanism: Screw lock for hands-free operation
• Surface treatment: Passivation to improve corrosion resistance
• Tests performed: Form test, boiling test and performance test
• Warranty: Lifetime warranty against defects in materials and workmanship
• Price (excl. tax as displayed): 50.95 EUR
• Availability status on page: Sold out
