Radiography system RADspeed Pro EDGE

digitalfor multipurpose radiographywith table

RADspeed Pro EDGE package is top-of the line General Radiography System in Shimadzu RADspeed family, which is featuring a variety of the latest cutting-edge applications like Tomosynthesis, Speed Stitch or Dual Energy Subtraction. Providing New Clinical Value Tomosynthesis (Digital Multi slice Tomography)OPTION(*) Tomosynthesis is a new digital imaging technology that combines cone-beam CT reconstruction with digital image processing. It allows images of any cross section to be obtained easily from volume data acquired from a single tomographic scan. - Flexible Examinations with Freedom in Choosing Body Positions This allows images to be obtained with loads applied in the standing position, or in the supine position on a table. Consequently, it can be used to obtain images of the elbow or knee in the bent position, which is difficult using CT. Display of Oblique Cross Sections Tilting the tomosynthesis cross section slightly from horizontal improves the visibility of spines, hip joints, and other areas that are not parallel to the tabletop. T-smartOPTION(*) “T-smart”, Tomosynthesis-Shimadzu Metal Artifact Reduction Technology, is our latest and highest grade tomosynthesis technology evolved further to reduce the metal artifacts with iterative reconstruction method. T-smart is useful especially for the prestigious orthopedic customers who are treating a lot of joint replacements with metal implants because T-smart is effective to see the adhesion degree between bone and implant. Speed Stitch (Auto stitching of long view images) The X-ray tube swings and the FPD moves automatically to capture image data.
