Electric patient lift PL30

battery-operatedon castersportable

Product overview
The Stela PL30 is an electric patient transfer chair that integrates commode and lifting functions in a single unit. Built on a steel frame with a 24V / 6000N motor, it provides controlled vertical transfer for patients and ergonomic operation for caregivers. The design supports hospital, clinic, rehabilitation and home-care settings where safe bed-chair-toilet transfers are required.

Highlights / Key features

• Multifunctional: transfer chair, commode and powered lifting device combined.
• Compact foldable design — two-step fold for storage/transport; folded dimensions 100 × 68 × 90 cm.
• Motor: 24V / 6000N with electric lift.
• Lift height: 850–1850 mm; lifting range indicated 500–1680 mm (both values reported on product data).
• Lifting speed: 8.3 mm/s for steady, controlled movement.
• Wheels: rear wheel plus 6" front wheel for stability and shock absorption.
• Handheld two-button remote control for up/down operation.
• Safety features: integrated emergency stop button and digital battery status indicator.
• Reference dimensions (H × W × L): 105 × 119 × 60 cm.
• Weight references: product weight 20–25 kg; gross weight ~41 kg.
• Load capacity: table indicates above 150 kg; page icons indicate 180 kg.

Usage / Applications

• Patient transfers between bed, chair and toilet.
• Use in hospitals, clinics, rehabilitation centres and long-term care facilities.
• Home-care and post-operative or mobility-impaired patient support.

Technical specifications

• Model: Stela PL30
• SKU: Stela-PL30
• Motor: 24V / 6000N
• Lift height: 850–1850 mm
• Lifting range: 500–1680 mm
• Lifting speed: 8.3 mm/s
• Load / weight capacity: listed as 180 kg (table indicates above 150 kg)
• Product weight: 20–25 kg
• Gross weight: ~41 kg
• Folded size: 100 × 68 × 90 cm (2-step fold)
• Reference dimensions (H × W × L): 105 × 119 × 60 cm
• Wheels: rear wheel & 6" front wheel
• Control: handheld two-button remote
• Safety: emergency stop button, battery status display
• Availability: In stock
• Displayed price: 5800.00 AED
